TEC3000 Series Single- or Two-Stage Economizer Thermostat Controllers Installation Instructions
31
Control Setup
(Cont)
Temp Control Setup Automatic PID
Tuning
Automatic PID Tuning, Manual PID
Tuning, Deadband Override, On/Off
Control (Single-stage Models)
Reset PID Tuning No Yes or No
Deadband* 0.7 to 1.5°F 1.0°F (-17.22 °C)
*Functionally, this is the PID deadband
when the Temp Control Setup is equal to
the Deadband Override or Manual PID
Tuning. When the Temp Control Setup
equals the On/Off Control, the Deadband
is used for the On/Off range of the stage
equipment. This parameter is hidden
when Temp Control Setup equals
Automatic PID Tuning.
Auto Economizer Tuning Enable Disable or Enable
Heat Prop Band* 160°F 5 to 10°F (-15 to -1.11°C)
*Values only appear when the Temp
control equals Manual PID Tuning.
Heat Integral Time* 729 seconds 300 to 1,600 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Heat Process Range* 40°F 10 to 100°F (-12.22 to 37.77°C)
*Values only appear when the Temp
control equals Manual PID Tuning.
Heat Saturation Time* 600 seconds 60 to 900 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Heat Time Constant* 720 seconds 360 to 1,440 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Heat Process Dead Time* 72 seconds 20 to 120 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Heat Period* 60 seconds 30 to 120 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Cool Prop Band* 160°F 5 to 10°F (-15 to -1.11°C)
*Values only appear when the Temp
control equals Manual PID Tuning.
Cool Integral Time* 729 seconds 300 to 1,600 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Cool Process Range* 40°F 10 to 100°F (-12.22 to 37.77°C)
*Values only appear when the Temp
control equals Manual PID Tuning.
Cool Saturation Time* 600 seconds 60 to 900 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Cool Time Constant* 720 seconds 360 to 1,440 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Cool Process Dead Time* 72 seconds 20 to 120 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Table 10: Menus and Submenus (Part 4 of 9)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
