TEC3000 Series Single- or Two-Stage Economizer Thermostat Controllers Installation Instructions
32
Control Setup
(Cont)
Cool Period* 60 seconds 30 to 120 seconds
*Values only appear when the Temp
control equals Manual PID Tuning.
Econ Prop Band* 160°F 5 to 10°F (-15 to -1.11°C)
*Values only appear when Auto
Economizer Tuning is Disabled.
Econ Integral Time* 729 seconds 300 to 1,600 seconds
*Values only appear when Auto
Economizer Tuning is Disabled.
Econ Process Range* 40°F 10 to 100°F (-12.22 to 37.77°C)
*Values only appear when Auto
Economizer Tuning is Disabled.
Econ Saturation Time* 600 seconds 60 to 900 seconds
*Values only appear when Auto
Economizer Tuning is Disabled.
Econ Time Constant* 720 seconds 360 to 1,440 seconds
*Values only appear when Auto
Economizer Tuning is Disabled.
Econ Process Dead Time* 72 seconds 20 to 120 seconds
*Values only appear when Auto
Economizer Tuning is Disabled.
Econ Period* 60 seconds 30 to 120 seconds
*Values only appear when Auto
Economizer Tuning is Disabled.
Equipment Size Normal Normal or Oversized
*Value only appears when Temp Control
Setup is not equal to On Off Control
Network Setup FC Comm Mode BACnet/MSTP BACnet/MSTP, N2
BACnet Instance ID* 1 0 to 4,914,302
* BACnet/MSTP communication mode
N2 Device Address* 4 1 to 255
* N2 Communication mode
BACnet Device Address* 4 4 to 127
* BACnet/MSTP communication mode
MSTP Baud Rate* Auto Auto, 1200, 9600, 19200, 38400, 76800
* BACnet/MSTP communication mode
BACnet Encoding Type
BACnet/MSTP Communication Mode
ISO 10646
(UCS-2)
ISO 10646 (UCS-2), ANSI X3.4
(US-ASCII)
Table 10: Menus and Submenus (Part 5 of 9)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
1
