TEC3000 Series Single- or Two-Stage Economizer Thermostat Controllers Installation Instructions
33
Equipment Setup General
Number of Compressor One-Stage Not Used, One-Stage, Two-Stage
Lead/Lag Equalize Runtime No Yes or No
Number of Heating Stages* Two-Stage Not Used, One-Stage, Two-Stage
* Heat pump unit,
Heat Pump supported = False
Compressor Min On Time 180 seconds 0 to 360 seconds
Compressor Min Off Time 180 seconds 0 to 360 seconds
Heating Min On Time 120 seconds 0 to 360 seconds
* Heat pump unit,
Heat Pump supported = False
Heating Min Off Time 120 seconds 0 to 360 seconds
* Heat pump unit
Equipment Setup
(Cont)
Supp Min On Time 120 seconds 0 to 360 seconds
* Heat pump unit,
Supp Heating Installed = True
Supp Min Off Time 120 seconds 0 to 360 seconds
* Heat pump unit,
Supp Heating Installed = True
Cooling Lockout Temp 40°F (4°C) 0 to 100°F (-18 to 38°C)
Heating Lockout Temp 80°F (27°C) 0 to 100°F (-18 to 38°C)
Unoccupied Off Delay 10 minutes 0 to 10 minutes
Economizer
Economizer Installed False True or False
Economizer Min Pos* 20% 0 to 100%
*Economizer = True
Closed Voltage* 2 VDC 0 to 10 VDC
*Economizer = True
Open Voltage* 10 VDC 0 to 10 VDC
*Economizer = True
Dry Bulb Sepoint 68°F (20°C) 0 to 100°F (-18 to 38°C)
*Economizer = True
Outdoor Enthalpy Setpoint 27 Btu/lb 0 to 100 Btu/lb dry air
*Economizer = True
Heat Pump
Heat Pump Supported False True or False
Supp Heating Installed* True True or False
* Heat Pump supported = True
Comp Low Lockout Temp* 32°F (0°C) -20 to 100°F (-29 to 38°C)
* Supp Heating Installed = True
Supp High OA Lockout Temp* 50°F (10°C) -20 to 100°F (-29 to 38°C)
* Supp Heating Installed = True
Rev Valve Polarity* Normally Heat Normally Heat, Normally Cool
* Heat Pump supported = True
Table 10: Menus and Submenus (Part 6 of 9)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
1
To Next Page
