Johnson Controls TIWM006B22S User Manual

34
P5417089
7.1.2 Maintenance for Flat Panel
● Gently wipe down using only a clean soft cloth. Using Benzene type thinners or chemical detergents
and abrasives as cleaning agents can damage the nish of plastic surfaces and louvers. In addition, pay
attention that the parts around the air outlet (louver, guide, etc.) may be damaged if an excessive force is
applied.
● The at panel can be removed using both hands and cleaned.
(2) Attaching Flat Panel
Insert both support arms into the recessed
openings and close the lid. Check that the
at panel is attached completely, and close
the at panel.
(1) Removing Flat Panel
Hold both ends of at panel and open it fully.
After the right arm shaft is expanded outward
and shafts are removed from the front panel, pull
the at panel forward while the right arm shaft is
expanded outward.
(1) Removing Flat Panel
Hold both sides of at panel and open it fully.
After the right arm shaft is pushed inward and
shafts are removed from the front panel, pull
the at panel forward while the right arm shaft is
slightly pushed inward.
(2) Attaching Flat Panel
Insert both support arms into the recessed
openings and close the lid. Check that the
at panel is attached completely, and close
the at panel.
NOTICE
TIWM006B22S to TIWM012B22S
TIWM015B22S to TIWM030B22S
Flat Panel
Remove this part
from the hole.
Expand the shaft
toward arrow
direction.
Hole
Guide at
Front Panel
Front Panel
Flat Panel
Flat Panel
Remove this part
from the hole.
Push the shaft
toward arrow
direction.
Flat Panel
Front Panel
Hole
Guide at
Front Panel
