Johnson Controls TM9V C Series User Manual

5750149-UIM-D-1219
Johnson Controls Ducted Systems 11
SECTION V: ELECTRICAL POWER
ELECTRICAL POWER CONNECTIONS
Field wiring to the unit must be grounded. Electric wires that are field
installed shall conform to the temperature limitation for 63°F (35°C) rise
wire when installed in accordance with instructions. Refer to Table 6 in
these instructions for specific furnace electrical data.
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
DANGER
PROPANE AND HIGH ALTITUDE CONVERSION KITS
It is very important to choose the correct kit and/or gas orifices for the altitude and the type of gas for which the furnace is being installed.
Only use natural gas in furnaces designed for natural gas. Only use propane (LP) gas for furnaces that have been properly converted to use pro-
pane (LP) gas. Do not use this furnace with butane gas.
Incorrect gas orifices or a furnace that has been improperly converted will create an extremely dangerous condition resulting in premature heat
exchanger failure, excessive sooting, high levels of carbon monoxide, personal injury, property damage, a fire hazard and/or death.
High altitude and propane (LP) conversions are required in order for the appliance to satisfactory meet the application.
An authorized distributor or dealer must make all gas conversions.
In Canada, a certified conversion station or other qualified agency, using factory specified and/or approved parts, must perform the conversion.
The installer must take every precaution to insure that the furnace has been converted to the proper gas orifice size when the furnace is installed.
Do not attempt to drill out any orifices to obtain the proper orifice size. Drilling out a gas orifice will cause misalignment of the burner flames, caus-
ing premature heat exchanger burnout, high levels of carbon monoxide, excessive sooting, a fire hazard, personal injury, property damage and/or
death.
!
CAUTION
Use copper conductors only.
!
Table 6: Ratings & Physical / Electrical Data
Model
Input
High/Low
Output
High/Low
Nominal
Airflow
Cabinet Width
High Fire
Air Temp. Rise
Low Fire
Air Temp. Rise
MBH kW MBH kW CFM
m
3
/min
in. cm °F °C °F °C
TM9V040A10 40/26 12/8 38/25 11/7 1000 28.3 14-1/2 36.8 30 - 60 17-33 20 - 50 11-28
TM9V060B12 60/39 18/11 58/37 17/11 1200 34 17-1/2 44.4 35 - 65 19-36 35 - 65 19-36
TM9V080B12 80/52 23/15 77/50 22/14 1200 34 17-1/2 44.4 40 - 70 22-39 35 - 65 19-36
TM9V080C16 80/52 23/15 77/50 22/14 1600 45.3 21 53.3 35 - 65 19-36 35 - 65 19-36
TM9V100C16 100/65 29/19 96/62 28/18 1600 45.3 21 53.3 35 - 65 19-36 30 - 65 17-33
TM9V100C20 100/65 29/19 96/62 28/18 2000 56.6 21 53.3 35 - 65 19-36 35 - 65 19-36
TM9V120D20 120/78 35/23 115/75 33/22 2000 56.6 24-1/2 62.2 35 - 65 19-36 35 - 65 19-36
Model
Max. Outlet
Air Temp.
Blower Blower Wheel Size AFUE
Total
Unit
Amps
Recommended
Fuse or
Circuit Breaker
Amps
Gas Pipe
Connection,
NPT
Operating
Weight
°F °C HP Amps inches cm % Lbs. kg.
TM9V040A10 190 88 1/2 7.7 11 x 8 27.9 x 20.3 96 9.6 15 1/2” 113 51.2
TM9V060B12 190 88 1/2 7.7 11 x 8 27.9 x 20.3 96 9.6 15 1/2” 122 55.3
TM9V080B12 190 88 1/2 7.7 11 x 8 27.9 x 20.3 96 9.6 15 1/2” 126 57.1
TM9V080C16 190 88 3/4 9.6 11 x 10 27.9 x 25.4 96 11.5 15 1/2” 136 61.7
TM9V100C16 190 88 3/4 9.6 11 x 10 27.9 x 25.4 96 11.5 15 1/2” 142 64.4
TM9V100C20 190 88 1 12.8 11 x 11 27.9 x 27.9 96 14.7 20 1/2” 145 65.7
TM9V120D20 190 88 1 12.8 11 x 11 27.9 x 27.9 96 14.7 20 1/2” 156 70.7
