UNIT WEIGHTS
When requested, equipment is supplied with optional
hanger brackets for use with up to a 3/8" diameter
hanger rod. See submittal drawings for hanger bracket
locations.
Hanger straps may be utilized as an alternate means of
suspending the equipment. Do not secure hanger straps
to electric heaters, coils or control enclosures. Hanger
straps can be mounted directly to the sides and bottom
of equipment casing, such that they do not interfere with
working components or access panels, using screws that
do not penetrate the unit cabinet more than 3/8".
When hanging equipment, always use the support
method as prescribed for rectangular duct in the job
specications.
Duct Connections
When fastening ductwork to equip-
ment, DO NOT use fasteners that
penetrate equipment cabinet more
than 3/8" [10mm]. Fasteners penetrat-
ing the equipment cabinet over 3/8"
[10mm] may come in contact with live
electrical parts or penetrate other com-
ponents within the equipment casing
causing damage.
All duct connections should be congured and installed
in accordance with SMACNA guidelines and all local
code requirements.
TABLE 4 - TSL WATER COIL WEIGHT
ADDS
UNIT
SIZE
# OF ROWS
1 ROW 2 ROW 3 ROW 4 ROW
10 9 (4) 12 (5) 15 (7) 18 (8)
12 11 (5) 15 (7) 19 (9) 23 (10)
14 13 (6) 18 (8) 22 (10) 27 (12)
16 15 (7) 21 (9) 27 (12) 32 (15)
Adds for water coils reect actual operating weight.
TABLE 1 - SINGLE DUCT TERMINAL UNIT WEIGHTS
UNIT
SIZE
TSS TSS w/ SA TSS w/ EH
SINGLE
WALL
DOU-
BLE
WALL
SINGLE
WALL
DOU-
BLE
WALL
SINGLE
WALL
DOU-
BLE
WALL
04 20 (9) 25 (11) 35 (16) 50 (23) 64 (29) 79 (36)
05 20 (9) 25 (11) 35 (16) 50 (23) 64 (29) 79 (36)
06 19 (9) 24 (11) 34 (15) 49 (22) 62 (28) 77 (35}
08 20 (9) 26 (12) 37 (17) 53 (24) 71 (32) 87 (39)
10 25 (11) 32 (15) 44 (20) 62 (28) 78 (35) 96 (44)
12 28 (13 36 (16) 50 (23) 71 (32) 89 (40) 110 (50)
14 35 (16) 44 (20) 59 (27) 84 (38) 106 (48) 131 (59)
16 37 (17) 47 (21) 63 (29) 90 (41) 113 (51) 140 (64)
19 49 (22) 62 (28) 85 (39) 120 (55) 141 (64) 176 (80)
22 51 (23) 65 (29) 90 (41) 127 (58) 148 (67) 185 (84)
TABLE 2 - TSS WATER COIL WEIGHT ADDS
UNIT
SIZE
# OF ROWS
1 ROW 2 ROW 3 ROW 4 ROW
04 4 (2) 5 (2) 8 (4) 12 (5)
05 4 (2) 5 (2) 8 (4) 12 (5)
06 4 (2) 5 (2) 8 (4) 12 (5)
08 4 (2) 6 (3) 9 (4) 13 (6)
10 5 (2) 8 (4) 12 (5) 18 (8)
12 7 (3) 10 (5) 16 (7) 22 (10)
14 9 (4) 14 (6) 21 (10) 30 (14)
16 10 (5) 16 (7) 24 (11) 34 (15)
19 12 (5) 20 (9) 28 (13) 40 (18)
22 13 (6) 22 (10) 32 (15) 44 (20)
Adds for water coils reect actual operating weight.
TABLE 3 - SINGLE DUCT LOW HEIGHT TERMINAL UNIT
WEIGHTS
UNIT
SIZE
TSL TSL w/ SA TSL w/ EH
SINGLE
WALL
DOUBLE
WALL
SINGLE
WALL
DOUBLE
WALL
SINGLE
WALL
DOUBLE
WALL
10 26 (12) 30 (14) 43 (19) 58 (26) 62 (28) 77 (35)
12 28 (13) 35 (16) 49 (22) 68 (31) 74 (34) 93 (42)
14 39 (18) 47 (21) 62 (28) 82 (37) 90 (41) 110 (50)
16 45 (20) 55 (25) 73 (33) 96 (44) 103 (47) 126 (57)
