Johnson Controls VA9310 Series User Manual

VA9310 Series Electric Non-Spring Return Valve Actuators Installation Instructions
10
Technical Specifications
VA9310 Series Electric Non-Spring Return Valve Actuator
Product Description VA9310-HGA-2: On/Off and floating mode VA9310-HGA-2: Proportional mode
Power Requirements 24 VAC (19.2 to 28.8 VAC) at 50/60, Class 2 (North America) or SELV (Europe), 6 VA
running. 24 VDC (21.6 to 28.8 VDC) Class 2 (North America) or SELV (Europe)
Transformer Sizing
requirements
<
6 VA
Input Signal/Adjustments 19.2 to 28.8 VAC at 50/60 Hz or 24 VDC
±10 Class 2 (North America) or SELV
(Europe)
0 (2) to 10 VDC or 0 (4) to 20 mA with field
furnished 500 ohm 1/4 W resistor
Offset: 0 to 10 VDC
SPAN: 2 to 10 VDC
Control Impedance 4.7k ohm 100k ohm
Feedback Signal – 0 (2) to 10 VDC
Rotation Range Mechanically limited to95±3
Rotation Time 90 seconds
Rotation Time Autocalibration 35 seconds
Cycles 100,000 full stroke cycles; 2,500,000 repositions
Audible Noise <35 dBA at 39-13/32 in. (1 m)
Electrical Connections 120 in. (3.05 m) UL 444 Type CMP plenum rated cable with 19 AWG cable (0.75 mm²)
conductors and 0.25 in. (6 mm) ferrule ends
Conduit Connections 1/2 in. NPSM (13 mm) threaded conduit connectors with M9300-100 conduit connector
Ambient Conditions Operating: -22 to 140F (-30 to 60C), 90% RH, noncondensing
Storage:
-40 to 185F (-40 to 85C), 95% RH, noncondensing
Fluid Temperature Limits
(Actuator and Valve Assembly)
VG12x1 and VG18x1 Series: 23 to 203F (-5 to 95C)
VG12x5 and VG18x5 Series: -22 to 212F (-30 to 100C)
VG12x5 and VG18x5 Series with M9000-561 Thermal Barrier Installed: -22 to 284F
(-30 to 140C) water; 15 psig (103 kPa) at 250F (121C) saturated steam
Enclosure IP54/NEMA 5
Dimensions See Table 2.
Shipping Weight 2 lb (0.9 kg)
Compliance United States:
UL Listed, CCN XAPX, File E27734, Under UL 60730, UL 60730-2-14,
Plenum Rated (UL 2043).
Canada:
UL Listed, CCN XAPX7, File E27734; Under CAN/CSA E60730 and CAN/CSA-E60730
Europe:
CE Mark – Johnson Controls, Inc. declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive and Low
Voltage Directive.
IEC 60730-1: Automatic Electrical Controls for Household and Similar Use, Part 1:
General Requirements and IEC 60730-2-14, Automatic Electrical Controls for Household
and Similar Use; Part 2 - Particular Requirements for Electric Actuators
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
