VA9310 Series Electric Non-Spring Return Valve Actuators Installation Instructions
2
Installation
Special Tools Needed
•T20 Torx™ screwdriver
• digital voltmeter or M9000-200 commissioning tool
(when zero and span need adjustment)
Accessories
Table 1: Accessories (Order Separately)
Code Number Description
M9000-200 Commissioning Tool That Provides a
Control Signal to Drive 24 V
On/Off, Floating, Proportional, and
Resistive Electric Actuators
M9000-341 Weathershield Kit
M9000-561 Thermal Barrier
M9300-1 Auxiliary Switch Kit (Single-Pole,
Double-Throw)
M9300-2 Auxiliary Switch Kit (Two Single-Pole,
Double-Throw)
M9300-100 Threaded Conduit Adapters for 1/2 in.
Electrician Fittings
M9300-140 Feedback Potentiometer 140k ohms
M9300-1K Feedback Potentiometer 1k ohms
M9300-2K Feedback Potentiometer 2k ohms
M9300-10K Feedback Potentiometer 10k ohms
