VFD66 User Guide 15
Issue Number: 2 www.johnsoncontrols.com
Safety information Rating data
Mechanical
installation
Electrical
installation
De-rating
Keypad and
display
Parameters Diagnostics
Technical
specifications
UL Listing
4.3.3 Emissions Compliance
An internal factory installed EMC filter is provided with all ratings, it is recommended
that it is kept in place unless there is a specific reason for removing it. This internal filter
reduces radio-frequency emissions into the line power supply. When the motor cable is
short, it permits the requirements of EN61800-3:2004 to be met for the second
environment with restricted distribution. For longer motor cables, the filter continues to
provide a useful reduction in emission level. When used with any length shielded motor
cable (up to the limit for the drive), it is unlikely that nearby industrial equipment will be
disturbed.
Installation of an additional external EMC filter as shown in Table 4-1, provides higher
levels of emissions compliance. If the application requires these levels of compliance
then the external filter must be installed in order to ensure compliance with EMC
regulations such as the EC EMC Directive, and to ensure the validity of the CE mark.
Table 4-1 Emmisions compliance for VFD66 based on EMC filter configuration
*The typical leakage current of the low leakage filter is 3mA compared to the standard
filter which has a typical leakage current of 40mA.
Table 4-2 Key to conformity
Notes:
(1) The first environment is one where the low voltage supply network also supplies
residential premises
(2) When distribution is restricted, drives are available only to installer with EMC
competence.
Motor
Cable
Length m
(ft)
Filter and Switching Frequency
Internal Filter Only Standard Filter Low Leakage Filter
Schaffner P/N: FS6514-14-07 Schaffner P/N: FS6514-14-07-LL*
3kHz 6kHz 12kHz 3kHz 6kHz 12kHz 3kHz 6kHz 12kHz
1 (3) C4C4C4 C2 C2 C3 C2 C2 C3
5 (16) C4 C4 C4 C2 C2 C3 C2 C2 C3
10 (33) C4 C4 C4 C2 C3 C3 C3 C3 C3
15 (50) C4 C4 C4 C2 C3 C3 C3 C3 C3
25 (82) C4 C4 C4 C2 C3 C3 C3 C3 C3
50 (164)C4C4C4 C2 C3 C3 C3 C3 C3
Compliance
Level
Standard Description Frequency
Range
Limits Application
C2
EN 61000-
6-4:2007
Generic emission
standard for the
Industrial
Environment
0.15 – 0.50
MHz
79dBμV quasi peak
66dBμV average
AC Supply Lines
0.50 – 30
MHz
73dBμV quasi peak
60dBμV average
EN 61800-
3:2004
IEC 61800-3
Product standard
for adjustable
power drive
systems.
Requirements for the first environment (1) with restricted
distribution (2).
C3
EN 61800-
3:2004
IEC 61800-3
Product standard
for adjustable
power drive
systems.
Requirements for the second environment with unrestricted
distribution.
C4
Requirements for the second environment with restricted
distribution (2).
