4.3.4 Immunity Compliance
The level of the drives immunity from conducted and radiated emissions from external
sources is summarised below in Table 4-3.
Table 4-3 Immunity compliance
Standard Type of immunity Test specification Application Level
IEC 61000-4-2
EN 61000-4-2
Electrostatic
discharge
6kV contact discharge
8kV air discharge
Module enclosure
Level 3
(industrial)
IEC 61000-4-3
EN 61000-4-3
Radio frequency
radiated field
10V/m prior to modulation
80 – 1000MHz
80% AM (1kHz)
modulation
Module enclosure
Level 3
(industrial)
IEC 61000-4-4
EN 61000-4-4
Fast transient
burst
5/50ns 2kV transient at
5kHz repetition
frequency via coupling
clamp
Control lines
Level 4
(industrial harsh)
5/50ns 2kV transient at
5kHz repetition frequency
by direct injection
Power lines
Level 3
(industrial)
IEC 61000-4-5
EN 61000-4-5 Surges
Common mode 4kV
1.2/50µs waveshape
AC supply lines:
Line to ground
Level 4
Differential mode 2kV
1.2/50µs waveshape
AC supply lines:
Line to line
Level 3
Lines to ground
Signal ports to
ground
Level 2
IEC 61000-4-6
EN 61000-4-6
Conducted radio
frequency
10V prior to modulation
0.15 – 80MHz
80% AM (1kHz)
modulation
Control and power
lines
Level 3
(industrial)
IEC 61000-4-11
EN 61000-4-11
Voltage dips and
interruptions
-30% 10ms
+60% 100ms
-60% 1s
<-95% 5s
AC power ports
IEC 61000-6-1
EN 61000-6-
1:2007
Generic immunity standard for the residential,
commercial and light – industrial environment
Complies
IEC 61000-6-2
EN 61000-6-
2:2005
Generic immunity standard for the industrial
environment
Complies
IEC 61800-3
EN 61800-3:2004
Product standard for adjustable speed power
drive systems (immunity requirements)
Meets immunity requirements for first and
second environments
