WT-4000 Series Pneumatic-to-Direct Digital Control (DDC) Room Thermostats Installation Instructions
17
Configuring the Room Thermostat for Stand-Alone
Operation
The WT-4000 Series Room Thermostats can be
configured in the field for stand-alone applications.
1. Press and hold the Shoulder button and the
Override button simultaneously for at least
6 seconds.
2. Press the Down button to enter the menu,
then press the press the Up button to select
Mesh on the menu (Figure 20).
3. Press to confirm the selection.
4. Press the Down button to select Standalone
on the menu.
5. Press to confirm the selection.
6. Press to return to the main screen. After the
room thermostat resets, a person icon appears in
the upper-right corner of the LCD indicating
stand-alone operation.
Stand-Alone Room Thermostat Configuration
To set the time and program the stand-alone room
thermostat occupancy schedule and temperature
setpoints:
1. Press and hold the Shoulder button and the
Override button simultaneously for
10 seconds to set the room thermostat in the
Configuration Mode. Initially, the LCD changes to
the firmware version screen, and then after
10 seconds the configuration menu appears.
Confirm that the first line in the configuration menu
shows Standalone; if it indicates Mesh, switch to
Standalone (Figure 21).
a. Press the Up button .
b. Press to select.
c. Press the Up button or the Down button
to change the value.
d. Press to confirm the selection.
-
+
Figure 20: Selecting Mesh
FIG:mntnce
N
et Config
F
an Mode
S
tandalone
M
aintenance
Mesh
-
+
+
-
Figure 21: Stand-Alone Menu
FIG:stndln
N
et Config
F
an Mode
S
tandalone
M
aintenance
S
tandalone
