SM-18003
5-29
EXTERNAL INPUT/OUTPUT AND FUNCTION SETTING
(58) Automatic Reset Temperature for Heating (F6)
Thisī˜ƒfunctionī˜ƒisī˜ƒutilizedī˜ƒtoī˜ƒsetī˜ƒtheī˜ƒautomaticī˜ƒresetī˜ƒtemperatureī˜ƒforī˜ƒHEATī˜ƒoperation.
Theī˜ƒsettingī˜ƒconditionsī˜ƒandī˜ƒtheī˜ƒautomaticī˜ƒresetī˜ƒtemperatureī˜ƒforī˜ƒheatingī˜ƒareī˜ƒasī˜ƒfollows:
(59) Operation Stoppage Prevention by Wired Controller Operational Error (F7)
Thisī˜ƒfunctionī˜ƒisī˜ƒutilizedī˜ƒtoī˜ƒpreventī˜ƒtheī˜ƒaccidentalī˜ƒoperationalī˜ƒstoppageī˜ƒcausedī˜ƒbyī˜ƒinadvertentlyī˜ƒ
pressingī˜ƒ(ON/OFF)ī˜ƒonī˜ƒtheī˜ƒwiredī˜ƒcontroller.ī˜ƒī˜ƒWhenī˜ƒthisī˜ƒfunctionī˜ƒisī˜ƒvalid,ī˜ƒtheī˜ƒoperationī˜ƒisī˜ƒstoppedī˜ƒbyī˜ƒ
pressingī˜ƒā€œ
ā€ī˜ƒ(ON/OFF)ī˜ƒbuttonī˜ƒonī˜ƒtheī˜ƒwiredī˜ƒcontrollerī˜ƒforī˜ƒmoreī˜ƒthanī˜ƒ3ī˜ƒseconds.ī˜ƒī˜ƒHowever,ī˜ƒtheī˜ƒenablingī˜ƒ
methodī˜ƒisī˜ƒnotī˜ƒchanged.
Operation Lock (60) to (63)
Fourī˜ƒoperationī˜ƒlockī˜ƒfunctionsī˜ƒareī˜ƒavailableī˜ƒasī˜ƒshownī˜ƒbelow.
Theseī˜ƒfunctionsī˜ƒareī˜ƒutilizedī˜ƒtoī˜ƒrestrictī˜ƒeachī˜ƒswitchī˜ƒoperationī˜ƒfromī˜ƒtheī˜ƒwiredī˜ƒcontroller.
Whenī˜ƒtheseī˜ƒfunctionsī˜ƒareī˜ƒvalid,ī˜ƒmodiīšæcationī˜ƒofī˜ƒeachī˜ƒfunctionī˜ƒisī˜ƒprohibited.
Allī˜ƒoperationī˜ƒlockī˜ƒfunctionsī˜ƒareī˜ƒvalidī˜ƒ(ā€œ01ā€ī˜ƒsetting)ī˜ƒbeforeī˜ƒshipment.
Eachī˜ƒswitchī˜ƒoperationī˜ƒbecomesī˜ƒunavailableī˜ƒbyī˜ƒpressingī˜ƒā€œ
ā€ī˜ƒandī˜ƒā€œBack/Helpā€ī˜ƒ(return)ī˜ƒbuttonsī˜ƒ
simultaneouslyī˜ƒforī˜ƒmoreī˜ƒthanī˜ƒ3ī˜ƒsecondsī˜ƒwhenī˜ƒtheseī˜ƒfunctionsī˜ƒareī˜ƒsetī˜ƒasī˜ƒā€œ01ā€.ī˜ƒī˜ƒTheī˜ƒindicationī˜ƒā€œ ā€ (operation
lockī˜ƒindicator)ī˜ƒisī˜ƒindicatedī˜ƒonī˜ƒtheī˜ƒwiredī˜ƒcontroller.ī˜ƒī˜ƒIfī˜ƒā€œ ā€ī˜ƒandī˜ƒā€œBack/Helpā€ī˜ƒ(return)ī˜ƒswitchesī˜ƒareī˜ƒpressedī˜ƒ
simultaneouslyī˜ƒforī˜ƒmoreī˜ƒthanī˜ƒ3ī˜ƒsecondsī˜ƒduringī˜ƒā€œ ā€ī˜ƒ(operationī˜ƒlockī˜ƒindicator)ī˜ƒisī˜ƒindicated,ī˜ƒā€œ ā€ indication
isī˜ƒturnedī˜ƒOFFī˜ƒandī˜ƒeachī˜ƒswitchī˜ƒoperationī˜ƒisī˜ƒavailable.ī˜ƒī˜ƒTheseī˜ƒfunctionsī˜ƒareī˜ƒtoī˜ƒrestrictī˜ƒtheī˜ƒoperationsī˜ƒofī˜ƒ
theī˜ƒwiredī˜ƒcontrollerī˜ƒonly.ī˜ƒī˜ƒIfī˜ƒoperationī˜ƒisī˜ƒpreformedī˜ƒfromī˜ƒtheī˜ƒcentralizedī˜ƒcontroller,ī˜ƒtheī˜ƒcommandī˜ƒfromī˜ƒtheī˜ƒ
centralizedī˜ƒcontrollerī˜ƒisī˜ƒgivenī˜ƒpriority.
(60) Lock Function for Operation Mode Selection (F8)
(61) Lock Function for Temperature Setting (F9)
(62) Lock Function for Fan Speed Selection (FA)
(63) Lock Function for Swing Louver Operation (Fb)
Settingī˜ƒCondition Settingī˜ƒTemperatureī˜ƒforī˜ƒAutomaticī˜ƒReset
62ī˜ƒ(17) 62
o
F (17
o
C)
64ī˜ƒ(18) 64
o
F (18
o
C)
66ī˜ƒ(19) 66
o
F (19
o
C)
68ī˜ƒ(20) 68
o
F (20
o
C)
70ī˜ƒ(21) 70
o
F (21
o
C)ī˜ƒ(Factory-Setting)
72ī˜ƒ(22) 72
o
F (22
o
C)
74ī˜ƒ(23) 74
o
F (23
o
C)
76ī˜ƒ(24) 76
o
F (24
o
C)
77ī˜ƒ(25) 77
o
F (25
o
C)
78ī˜ƒ(26) 78
o
F (26
o
C)
80ī˜ƒ(27) 80
o
F (27
o
C)
82ī˜ƒ(28) 82
o
F (28
o
C)
84ī˜ƒ(29) 84
o
F (29
o
C)
86ī˜ƒ(30) 86
o
F (30
o
C)
