EXTERNAL INPUT/OUTPUT AND FUNCTION SETTING
(64) Cooling Lower Limit for Setting Temperature (FC)
ThisfunctionisutilizedtolimitthelowestsettingtemperatureforFAN/COOL/DRYoperations.
Whenthisfunctionisvalid,itprovidestheappropriatecoolingoperationandenergysaving.
Thesettingconditionsandtheminimumsettingtemperatureforcoolingareasfollows:
 <Example>
(65) Heating Upper Limit for Setting Temperature (Fd)
ThisfunctionisutilizedtolimitthehighestsettingtemperatureforHEAToperation.
Whenthisfunctionisvalid,itprovidestheappropriateheatingoperationandenergysaving.
Thesettingconditionsandtheheatingupperlimitforthesettingtemperatureareasfollows:
 <Example>
SettingCondition Details
MinimumSettingTemperature
(FAN/COOL/DRY)*
00 StandardValue 66
o
F (19
o
C)
01 LowerLimit+2
o
F(LowerLimit+1
o
C) 68
o
F (20
o
C)
02 LowerLimit+4
o
F(LowerLimit+2
o
C) 70
o
F (21
o
C)
03 LowerLimit+6
o
F(LowerLimit+3
o
C) 72
o
F (22
o
C)
04 LowerLimit+8
o
F(LowerLimit+4
o
C) 74
o
F (23
o
C)
05 LowerLimit+10
o
F(LowerLimit+5
o
C) 76
o
F (24
o
C)
06 LowerLimit+11
o
F(LowerLimit+6
o
C) 77
o
F (25
o
C)
07 LowerLimit+12
o
F(LowerLimit+7
o
C) 78
o
F (26
o
C)
08 LowerLimit+14
o
F(LowerLimit+8
o
C) 80
o
F (27
o
C)
09 LowerLimit+16
o
F(LowerLimit+9
o
C) 82
o
F (28
o
C)
10 LowerLimit+18
o
F(LowerLimit+10
o
C) 84
o
F (29
o
C)
 *IncaseofStandardUnit
SettingCondition Details
SettingTemperatureUpperLimit
(HEAT)*
00 StandardValue 86
o
F (30
o
C)
01 UpperLimit-2
o
F(UpperLimit-1
o
C) 84
o
F (29
o
C)
02 UpperLimit-4
o
F(UpperLimit-2
o
C) 82
o
F (28
o
C)
03 UpperLimit-6
o
F(UpperLimit-3
o
C) 80
o
F (27
o
C)
04 UpperLimit-8
o
F(UpperLimit-4
o
C) 78
o
F (26
o
C)
05 UpperLimit-9
o
F(UpperLimit-5
o
C) 77
o
F (25
o
C)
06 UpperLimit-10
o
F(UpperLimit-6
o
C) 76
o
F (24
o
C)
07 UpperLimit-12
o
F(UpperLimit-7
o
C) 74
o
F (23
o
C)
08 UpperLimit-14
o
F(UpperLimit-8
o
C) 72
o
F (22
o
C)
09 UpperLimit-16
o
F(UpperLimit-9
o
C) 70
o
F (21
o
C)
10 UpperLimit-18
o
F(UpperLimit-10
o
C) 68
o
F (20
o
C)
11 UpperLimit-20
o
F(UpperLimit-11
o
C) 66
o
F (19
o
C)
12 UpperLimit-22
o
F(UpperLimit-12
o
C) 64
o
F (18
o
C)
 *IncaseofStandardUnit
Factory-Setting: "00"
(Lower Limit 66+0=66
o
F (19+0=19
o
C))
Setting Condition: "06"
(Lower Limit 66+1
1=77
o
F (19+6=25
o
C))
66
o
F
(19
o
C)
86
o
F
(30
o
C)
86
o
F
(30
o
C)
77
o
F
(25
o
C)
Temperature Setting: Available
Setting Temperature at Wired Controller
Temperature Setting
: Not Available
Temperature Setting
: Available
Factory-Setting: "00"
(Upper Limit 86-0=86
o
F (30-0=30
o
C))
Setting Condition: "09"
(Upper Limit 86-16=70
o
F (30-9=21
o
C))
64
o
F
(18
o
C)
86
o
F
(30
o
C)
64
o
F
(18
o
C)
70
o
F
(21
o
C)
Setting Temperature at Wired Controller
Temperature Setting: Available
Temperature Setting
: Not Available
Temperature Setting
: Available
