Johnson Controls York YCAL0014E Series User Manual

YORK INTERNATIONAL
6
FORM 150.62-NM6 (LS1)
Two Field Provided Power Supply Circuits to the chiller. Field connections to Factory Provided Terminal Blocks (standard), Non-Fused Discon-
nect Switches (optional), or Individual System Circuit Breakers (optional) per electrical system
ELECTRICAL DATA – MULTIPLE POINT POWER SUPPLY CONNECTIONS – YCAL0090E_ - YCAL0134E_
TABLE 5 – MULTIPLE POINT POWER SUPPLY CONNECTIONS
MODEL
YCAL
VOLT HZ
SYSTEM #2 FIELD SUPPLIED WIRING
MCA
1
MIN N/F
DISC SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
TERMINAL BLOCK
(std)
NF DISC. SWITCHES
(opt)
CIR BREAKERS (opt)
MIN
3
MAX
4
MIN MAX
0090
200 60
181 200 225 250 225 250 # 10 - 300 (1) # 4 - 300 (1) # 4 - 300
230 60
168 200 200 225 200 225 # 10 - 300 (1) # 4 - 300 (1) # 4 - 300
380 60
98 150 125 125 125 125 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
460 60
81 100 90 110 100 110 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
575 60
65 100 80 90 80 90 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0094
200 60
221 250 250 300 250 300 # 10 - 300 (1) # 6 - 350 # 6 - 350
230 60
206 250 250 250 250 250 # 10 - 300 (1) # 4 - 300 # 6 - 350
380 60
120 150 150 150 150 150 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60
99 150 110 125 110 125 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
575 60
79 100 90 100 90 100 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0104
200 60
221 250 250 300 250 300 # 10 - 300 (1) # 6 - 350 # 6 - 350
230 60
206 250 250 250 250 250 # 10 - 300 (1) # 4 - 300 # 6 - 350
380 60
120 150 150 150 150 150 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60
99 150 110 125 110 125 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
575 60
79 100 90 100 90 100 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0114
200 60
251 400 300 300 300 300 # 4 - 500 250 - 500 250 - 500
230 60
233 250 250 250 250 250 # 4 - 500 250 - 500 250 - 500
380 60
135 150 150 150 150 150 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60
112 150 125 125 125 125 # 10 - 3/0 (1) # 6 - 350 # 3 - 3/0
575 60
89 100 100 110 100 110 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0124
200 60
259 400 300 300 300 300 # 4 - 500 250 - 500 250 - 500
230 60
241 400 300 300 300 300 # 4 - 500 250 - 500 250 - 500
380 60
140 150 150 175 150 175 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60
116 150 125 125 125 125 # 10 - 3/0 (1) # 6 - 350 # 3 - 3/0
575 60
92 100 100 110 100 110 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0134
200 60
317 400 350 400 350 400 # 4 - 500 250 - 500 250 - 500
230 60
294 400 350 350 350 350 # 4 - 500 250 - 500 250 - 500
380 60
171 200 200 200 200 200 # 10 - 3/0 # 6 - 350 # 6 - 350
460 60
141 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 3 - 3/0
575 60
113 150 125 125 125 125 # 12 - # 1 # 6 - 350 # 3 - 3/0
MODEL
YCAL
VOLT HZ
SYSTEM #1 FIELD SUPPLIED WIRING
MCA
1
MIN N/F
DISC SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
TERMINAL BLOCK
(std)
NF DISC. SWITCHES
(opt)
CIR BREAKERS (opt)
MIN
3
MAX
4
MIN MAX
0090
200 60 221 250 250 300 250 300 # 10 - 300 (1) # 6 - 350 (1) # 6 - 350
230 60 206 250 250 250 250 250 # 10 - 300 (1) # 4 - 300 (1) # 6 - 350
380 60 120 150 150 150 150 150 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60 99 150 110 125 110 125 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
575 60 79 100 90 100 90 100 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0094
200 60 221 250 250 300 250 300 # 10 - 300 (1) # 6 - 350 (1) # 6 - 350
230 60 206 250 250 250 250 250 # 10 - 300 (1) # 4 - 300 (1) # 6 - 350
380 60 120 150 150 150 150 150 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60 99 150 110 125 110 125 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
575 60 79 100 90 100 90 100 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0104
200 60 251 400 300 300 300 300 # 4 - 500 250 - 500 250 - 500
230 60 233 250 250 250 250 250 # 4 - 500 250 - 500 250 - 500
380 60 135 150 150 150 150 150 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60 112 150 125 125 125 125 # 10 - 3/0 (1) # 6 - 350 # 3 - 3/0
575 60 89 100 100 110 100 110 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0114
200 60 251 400 300 300 300 300 # 4 - 500 250 - 500 250 - 500
230 60 233 250 250 250 250 250 # 4 - 500 250 - 500 250 - 500
380 60 135 150 150 150 150 150 # 14 - 2/0 (1) # 6 - 350 # 6 - 350
460 60 112 150 125 125 125 125 # 14 - 2/0 (1) # 6 - 350 # 3 - 3/0
575 60 89 100 100 110 100 110 # 14 - 2/0 (1) # 6 - 350 # 3 - 3/0
0124
200 60 317 400 350 400 350 400 # 4 - 500 250 - 500 250 - 500
230 60 294 400 350 350 350 350 # 4 - 500 250 - 500 250 - 500
380 60 171 200 200 200 200 200 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
460 60 141 200 175 175 175 175 # 10 - 3/0 (1) # 6 - 350 # 6 - 350
575 60 113 150 125 125 125 125 # 12 - # 1 (1) # 6 - 350 # 3 - 3/0
0134
200 60 317 400 350 400 350 400 # 4 - 500 250 - 500 250 - 500
230 60 294 400 350 350 350 350 # 4 - 500 250 - 500 250 - 500
380 60 171 200 200 200 200 200 # 10 - 3/0 # 6 - 350 # 6 - 350
460 60 141 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 6 - 350
575 60 113 150 125 125 125 125 # 12 - # 1 # 6 - 350 # 3 - 3/0
