JOHNSON CONTROLS
36
FORM 150.62-NM6 (103)
PHYSICAL DATA (METRIC)
YCAL0014E_ - YCAL0124E_
Installation
Model Number YCAL
0014 0020 0024 0030 0034 0040 0042 0044
General Unit Data
Nominal kW, R-22 46.4 63.3 78.8 99.5 119.6 136.1 150.9 165.7
Nominal kW, R-407C 44.7 61.2 76.3 93.9 111.5 127.7 141.4 155.1
Number of Refrigerant Circuits 1 1 1 1 1 2 2 2
Refrigerant Charge
R-22, ckt1 / ckt2, kg 14.5 17.3 24.4 29.5 31.4 20.5/20.5 24.5/20.5 24.5/24.5
R-407C, ckt1 / ckt2, kg 14.5 17.3 24.4 29.5 31.4 20.5/20.5 24.5/20.5 23.5/23.5
Oil Charge, ckt1 / ckt2, liters 8.3 8.3 8.3 8.3 12.5 8.3/8.3 8.3/8.3 8.3/8.3
Shipping Weight
Aluminum Fin Coils, kg 1121 1129 1296 1330 1487 2127 2155 2187
Copper Fin Coils, kg 1189 1197 1364 1398 1555 2263 2292 2323
Operating Weight
Aluminum Fin Coils, kg 1156 1163 1334 1377 1534 2237 2265 2297
Copper Fin Coils, kg 1224 1231 1402 1445 1602 2373 2401 2433
Compressors, scroll type
Compressors per circuit 2 2 2 2 3 2 2 2
Compressors per unit 2 2 2 2 3 4 4 4
Nominal kWo per compressor 26 35 46 53 46 35/35 46/35 46/46
Condenser
Total Face Area meters
2
4 4 6 6 6 12 12 12
Number of Rows 2 2 2 3 3 2 2 2
Fins per m 512 512 512 512 512 512 512 512
Condenser Fans
Number of Fans total 2 2 2 2 2 4 4 4
Fan hp/kw 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4
Fan RPM 1140 1140 1140 1140 1140 1140 1140 1140
Number of Blades 3 3 3 3 3 3 3 3
Total Chiller Airow l/s 7672 7672 11091 11091 11091 22351 22351 22351
Evaporator, Direct Expansion
Diameter x Length 203x1829 203x1830 203x1981 210x2134 210x2134 248x2438 248x2438 248x2438
Water Volume, liters 34.9 34.9 37.7 46.7 46.7 110.3 110.3 110.3
Maximum Water Side Pressure, bar 10 10 10 10 10 10 10 10
Maximum Refrigerant Side Pressure, bar 24 24 24 24 24 24 24 24
Minimum Chiller Water Flow Rate, l/s 1.6 1.6 1.9 2.2 3.8 3.8 3.8 3.8
Maximum Chiller Water Flow Rate, l/s 3.8 3.8 4.4 10.7 10.7 18.9 18.9 18.9
Water Connections, inches 3 3 3 4 4 6 6 6
