JOHNSON CONTROLS
35
FORM 150.62-NM6 (103)
PHYSICAL DATA (ENGLISH)
YCAL0014E_ - YCAL0124E_
1
Model Number YCAL
0050 0060 0064 0070 0074 0080 0090 0094 0104 0114 0124
51.1 56.2 63.1 70.2 76.0 82.2 83.2 89.9 99.6 111.1 121.0
48.1 53.3 58.9 65.7 71.6 78.0 79.6 85.8 94.9 106.5 115.1
2 2 2 2 2 2 2 2 2 2 2
60/54 72/72 75/62 75/75 92/83 100/100 94/77 94/94 112/94 112/112 137/112
60/54 57/57 67/57 67/67 88/67 88/88 90/74 90/90 108/90 108/108 132/108
2.2/2.2 2.2/2.2 3.3/3.3 3.3/3.3 3.3/3.3 3.3/3.3 4.2/4.2 4.2/4.2 6.3/4.2 6.3/6.3 6.3/6.3
4906 4994 5866 6045 6217 6448 6541 6619 7434 8824 8842
5206 5294 6166 6425 6597 6828 7369 7448 8378 10083 10107
5148 5236 6208 6386 6558 6779 6981 7059 7923 9313 9331
5517 5605 6651 6829 7001 7222 7809 7888 8867 10572 10596
2 2 3 3 3 3 2 2 3/2 3 3
4 4 6 6 6 6 4 4 5 6 6
15/13 15/15 13/10 13/13 15/13 15/15 25/20 25/25 20/25 20/20 25/20
128.0 128.0 149.3 149.3 149.3 149.3 168.0 168.0 192.0 222.0 222.0
2 3 2 3 3 3 3 3 3 3 3
13 13 13 13 13 13 13 13 13 13 13
4 4 4 4 4 4 6 6 6 8 8
2 / 1.4 2 / 1.4 2 / 1.7 2 / 1.7 2 / 1.7 2 / 1.7 2/1.8 2/1.8 2/1.8 2/1.8 2/1.8
1140 1140 1140 1140 1140 1140 1140 1140 1140 1140 1140
3 3 3 3 3 3 3 3 3 3 3
47360 46080 55253 55253 54550 53760 79800 79800 85800 106400 106400
10”x8’ 10”x8’ 12”x8’ 12”x8’ 12”x8’ 12”x8’ 14”x8’ 14”x8’ 15”x8’ 15”x8’ 15”x8’
29.1 29.1 41.2 41.2 41.2 39.9 53.0 53.0 58.9 58.9 58.9
150 150 150 150 150 150 150 150 150 150 150
350 350 350 350 350 350 350 350 350 350 350
60 60 100 100 100 100 125 138 150 165 180
300 300 350 350 350 385 525 525 625 625 625
6 6 6 6 6 6 8 8 8 8 8
"Replacement
information at
back of manual"
