Johnson Controls York YCAL0014E Series User Manual

JOHNSON CONTROLS
22
FORM 150.62-NM6 (103)
ELECTRICAL DATA – DUAL POINT POWER SUPPLY CONNECTIONS – YCAL0040E_ - YCAL0080E_
See Notes and Legend on page 19.
TABLE 3 – DUAL POINT POWER SUPPLY CONNECTIONS
(Two Field Provided Power Supply Circuits to the chiller. Field connections to Factory Provided Terminal Blocks per system)
Installation
MODEL
YCAL
VOLT HZ
SYSTEM #1 FIELD SUPPLIED WIRING SYSTEM #1 COMPRESSOR & FAN
MCA
1
MIN N/
F DISC
SW
2
D.E. FUSE CKT. BKR.
5
INCOMING
(LUGS) WIRE
RANGE
6
COMPR. #1 COMPR. #2 COMPR. #3 FANS
MIN
3
MAX
4
MIN MAX RLA LRA RLA LRA RLA LRA QTY FLA(EA)
0040
200 60 92 100 100 110 100 110 # 10 - # 1 33.2 278 33.2 278 — — 2 8.2
230 60 91 100 100 110 100 110 # 10 - # 1 33.2 278 33.2 278 — — 2 7.8
380 60 55 60 60 70 60 70 # 10 - # 1 19.9 151 19.9 151 — — 2 4.8
460 60 46 60 50 60 50 60 # 10 - # 1 16.6 127 16.6 127 — — 2 4.0
575 60 37 60 40 45 40 45
# 10 - # 1
13.3 100 13.3 100 — — 2 3.1
0042
200 60 107 150 125 125 125 125
# 10 - # 1
40.0 350 40.0 350 — — 2 8.2
230 60 106 150 125 125 125 125 # 10 - # 1 40.0 350 40.0 350 — — 2 7.8
380 60 64 100 70 90 70 90 # 10 - # 1 24.0 195 24.0 195 — — 2 4.8
460 60 53 60 60 70 60 70
# 10 - # 1
19.9 167 19.9 167 — — 2 4.0
575 60 43 60 50 50 50 50 # 10 - # 1 16.0 125 16.0 125 — — 2 3.1
0044
200 60 107 150 125 125 125 125
# 10 - # 1
40.0 350 40.0 350 — — 2 8.2
230 60 106 150 125 125 125 125 # 10 - # 1 40.0 350 40.0 350 — — 2 7.8
380 60 64 100 70 80 70 80 # 10 - # 1 24.0 195 24.0 195 — — 2 4.8
460 60 53 60 60 70 60 70 # 10 - # 1 19.9 167 19.9 167 — — 2 4.0
575 60 43 60 50 50 50 50
# 10 - # 1
16.0 125 16.0 125 — — 2 3.1
0050
200 60 124 150 150 150 150 150
# 10 - 3/0
47.8 425 47.8 425 — — 2 8.2
230 60 124 150 150 150 150 150 # 10 - 3/0 47.8 425 47.8 425 — — 2 7.8
380 60 75 100 90 100 90 100 # 10 - # 1 28.7 239 28.7 239 — — 2 4.8
460 60 62 100 70 80 70 80 # 10 - # 1 23.9 198 23.9 198 — — 2 4.0
575 60 50 60 60 60 60 60
# 10 - # 1
19.1 148 19.1 148 — — 2 3.1
0060
200 60 124 150 150 150 150 150
# 10 - 3/0
47.8 425 47.8 425 — — 2 8.2
230
60 124 150 150 150 150 150 # 10 - 3/0 47.8 425 47.8 425 — — 2 7.8
380 60 75 100 90 100 90 100 # 10 - # 1 28.7 239 28.7 239 — — 2 4.8
460 60 62 100 70 80 70 80 # 10 - # 1 23.9 198 23.9 198 — — 2 4.0
575 60 50 60 60 60 60 60
# 10 - # 1
19.1 148 19.1 148 —- — 2 3.1
0064
200 60 147 200 175 175 175 175
# 10 - 3/0
40.0 350 40.0 350 40.0 350 2 8.2
230 60 146 200 175 175 175 175 # 10 - 3/0 40.0 350 40.0 350 40.0 350 2 7.8
380 60 88 100 100 110 100 11
0 # 10 - # 1 24.0 195 24.0 195 24.0 195 2 4.8
460 60 73 100 80 90 80 90 # 10 - # 1 19.9 167 19.9 167 19.9 167 2 4.0
575 60 59 100 70 70 70 70
# 10 - # 1
16.0 125 16.0 125 16.0 125 2 3.1
0070
200 60 147 200 175 175 175 175
# 10 - 3/0
40.0 350 40.0 350 40.0 350 2 8.2
230 60 146 200 175 175 175 175 # 10 - 3/0 40.0 350 40.0 350 40.0 350 2 7.8
380 60 88 100 100 110 100 110 # 10 - # 1 24.0 195 24.0 195 24.0 195 2 4.8
460 60 73 100 80 90 80 90
# 10 - # 1
19.9 167 19.9 167 19.9 167 2 4.0
575 60 59 100 70 70 70 70 # 10 - # 1 16.0 125 16.0 125 16.0 125 2 3.1
0074
200 60 172 200 200 200 200 200
# 10 - 3/0
47.8 425 47.8 425 47.8 425 2 8.2
230 60 171 200 200 200 200 200 # 10 - 3/0 47.8 425 47.8 425 47.8 425 2 7.8
380 60 103 150 125 125 125 125 # 10 - # 1 28.7 239 28.7 239 28.7 239 2 4.8
460 60 86 100 100 100 100 100
# 10 - # 1
23.9 198 23.9 198 23.9 198 2 4.0
575 60 69 100 80 80 80 80 # 10 - # 1 19.1 148 19.1 148 19.1 148 2 3.1
0080
200 60 172 200 200 200 200 200
# 10 - 3/0
47.8 425 47.8 425 47.8 425 2 8.2
230 60 171 200 200 200 200 200 # 10 - 3/0 47.8 425 47.8 425 47.8 425 2 7.8
380 60 103 150 125 125 125 125 # 10 - # 1 28.7 239 28.7 239 28.7 239 2 4.8
460 60 86 100 100 100 100 100
# 10 - # 1
23.9 198 23.9 198 23.9 198 2 4.0
575 60 69 100 80 80
80 80 # 10 - # 1 19.1 148 19.1 148 19.1 148 2 3.1
