JOHNSON CONTROLS
57
FORM 150.62-NM6 (103)
C
SIDE VIEW
HOLES (EACH SIDE)
(2) 76 X 76 RIGGING
G
286
X
Z
616
WATER OUTLET
6"
A
2146
1791
3022
WATER INLET
6"
859
737
2282
229
53
A
19 DIA.
2045
TOP VIEW
C
G
Y
X
1270
38
HOLES (TYP.)
MOUNTING
387
38
POWER PANEL
CONTROL PANEL
ORIGIN
248
2527
AB
CD
LD04875A
ALUMINUM
COPPER
1
YCAL
Center of Gravity (mm)
X Y Z
0040 1490 1021 1047
0042 1481 1026 1009
0044 1483 1021 1004
0050 1484 1025 1003
0060 1485 1021 1001
YCAL
Center of Gravity (mm)
X Y Z
0040 1482 1021 1023
0042 1483 1026 1018
0044 1485 1021 1013
0050 1486 1025 1012
0060 1487 1021 1010
