FORM 150.62-NM6 (103)
3022
616 1791
280 2159
(2) 76 X 76 RIGGING
HOLES (EACH SIDE)
6"
WATER INLETWATER OUTLET
6"
2311
521
1270
19 DIA.
MOUNTING
HOLES (TYP.)
2473
737
859
38
38
C
G
Z
X
A
A
SIDE VIEW
53
229
CONTROL PANEL
248
ORIGIN
Y
2527
POWER PANEL
TOP VIEW
C
G
X
A B
C D
LD04879A
ALUMINUM
COPPER
1
YCAL
Center of Gravity (mm)
X Y Z
0064 1435 1162 1001
0070 1437 1154 1002
0074 1438 1161 1003
0080 1437 1154 991
YCAL
Center of Gravity (mm)
X Y Z
0064 1440 1162 1016
0070 1442 1154 1017
0074 1443 1160 1018
0080 1442 1154 1006
