Johnson Controls York YKN2Open board User Manual

J5 (Discharge)
Temperature Heater Voltage Temperature Heater Voltage
(°C) (Ohms) (V) (°C) (Ohms) (V)
59 2582 2,81755 105 586 1,13302
60 2490 2,77283 106 569 1,10743
61 2402 2,72831 107 553 1,08304
62 2318 2,68411 108 538 1,05989
63 2237 2,63984 109 523 1,03646
64 2159 2,59558 110 509 1,01435
65 2085 2,55202 111 495 0,99198
66 2013 2,50810 112 481 0,96937
67 1944 2,46450 11 3 468 0,94814
68 1878 2,42135 114 455 0,92668
69 1814 2,37808 115 443 0,90667
70 1753 2,33546 116 431 0,88647
71 1694 2,29291 117 419 0,86606
72 1638 2,25124 118 408 0,84718
73 1583 2,20904 119 397 0,82812
74 1531 2,16794 120 387 0,81064
75 1481 2,12726 121 377 0,79302
76 1433 2,08710 122 367 0,77524
77 1386 2,04666 12 3 357 0,75732
78 1341 2,00688 124 348 0,74106
79 1298 1,96786 125 339 0,72467
80 1256 1,92875 126 330 0,70815
81 1216 1,89055 127 322 0,69337
82 1178 1,85337 128 314 0,67848
83 1141 1,81630 129 306 0,66349
84 1105 1,77939 130 298 0,64839
85 1070 1,74267 131 291 0,63509
86 1037 1,70728 132 283 0,61980
87 1005 1,67221 133 276 0,60633
88 974 1,63753 134 270 0,59471
89 944 1,60326 135 263 0,58109
90 915 1,56947 136 256 0,56738
91 888 1,53740 137 250 0,55556
92 861 1,50472 138 244 0,54367
93 853 1,49492 139 238 0,53172
94 810 1,44128 140 232 0,51971
95 786 1,41062 141 226,8 0,50925
96 763 1,38075 142 221,6 0,49874
97 740 1,35036 14 3 216,4 0,48818
98 719 1,32218 144 211,2 0,47757
99 698 1,29355 145 206 0,46691
100 677 1,26448 146 201,4 0,45744
101 658 1,23777 147 196,8 0,44792
102 639 1,21069 148 192,2 0,43837
103 621 1,18466 149 187,6 0,42878
104 603 1,15828 150 183 0,41915
N O T E
Reading of the value:
• Resistance value in Ω, with the probe disconnected from the YKN2Open board.
• Voltage value in Ω, with the probe connected to the YKN2Open board between two terminals of the
probe.
