7.1 Tables
The following tables indicate the relationship between the temperature, resistance and voltage of the
following probes: discharge, liquid, suction, outdoor, water, supply and return.
J5 (Discharge)
Temperature
Heater Voltage Temperature Heater Voltage
(°C) (Ohms) (V) (°C) (Ohms) (V)
-40 328400 4,96973 7 22952 4,59923
-39 310260 4,96798 8 21865 4,58098
-38 292120 4,96600 9 20836 4,56209
-37 273980 4,96377 10 19860 4,54254
-36 255840 4,96122 11 18936 4,52235
-35 237700 4,95828 12 18060 4,50150
-34 224940 4,95594 13 17229 4,47995
-33 212180 4,95331 14 16441 4,45773
-32 199420 4,95035 15 15694 4,43484
-31 186660 4,94699 16 14984 4,41121
-30 173900 4,94315 17 14311 4,38692
-29 164820 4,94006 18 13671 4,36188
-28 155740 4,93660 19 13064 4,33617
-27 146660 4,93273 20 12487 4,30973
-26 137580 4,92836 21 11938 4,28254
-25 128500 4,92337 22 11417 4,25468
-24 121101 4,91877 23 10921 4,22607
-23 114172 4,91392 24 10449 4,19672
-22 107681 4,90883 25 10001 4,16674
-21 101597 4,90347 26 9574 4,13599
-20 95893 4,89785 27 9167 4,10450
-19 90543 4,89194 28 8780 4,07236
-18 85523 4,88574 29 8412 4,03957
-17 80811 4,87924 30 8060 4,00596
-16 76386 4,87243 31 7726 3,97183
-15 72229 4,86528 32 7407 3,93696
-14 68322 4,85780 33 7103 3,90146
-13 64650 4,84996 34 6813 3,86531
-12 61196 4,84176 35 6536 3,82849
-11 57947 4,83319 36 6272 3,79110
-10 54890 4,82422 37 6020 3,75312
-9 52011 4,81485 38 5780 3,71465
-8 49300 4,80507 39 5550 3,67550
-7 46746 4,79485 40 5331 3,63593
-6 44339 4,78420 41 5122 3,59590
-5 42069 4,77308 42 4921 3,55512
-4 39929 4,76150 43 4730 3,51412
-3 37910 4,74944 44 4547 3,47258
-2 36004 4,73687 45 4373 3,43088
-1 34205 4,72380 46 4205 3,38840
0 32506 4,71020 47 4046 3,34601
1 30902 4,69607 48 3893 3,30307
2 29385 4,68138 49 3746 3,25966
3 27952 4,66613 50 3606 3,21620
4 26596 4,65030 51 3472 3,17251
5 25314 4,63389 52 3343 3,12839
6 24101 4,61687 53 3220 3,08429
54 3102 3,03998
55 2989 2,99559
56 2881 2,95124
57 2777 2,90664
58 2677 2,86188
7 Temperature tables
7.1 Tables
28
