Johnson Controls York ZH Series User Manual

5167515-YIM-H-0518
Johnson Controls Ducted Systems 15
Figure 15: ZH078-150 Roof Curb
Figure 16: ZH078-150 Transition Roof Curb
Table 7: Left/End Duct Dimensions
Unit Model Number
Dimension (in.)
ABC
ZH078 30.357 13.365 22.516
ZH090 30.357 13.365 22.516
ZH102 30.358 22.580 22.330
ZH120 30.358 22.580 22.330
ZH150 30.358 22.580 22.330
8 or 14
50-1/2
30
20
20
80-5/8
6
2TYP.
INSULATED DECK UNDER
COMPRESSOR SECTION
INSULATED DECK UNDER
CONDENSER SECTION
FRONT
RIGHT
SUPPLY
RETURN
76-5/8
94
50-1/2
30-1/2
64-1/4
59-1/4
10
23
4
26
80-5/8
2TYP
FRONT
RIGHT
SUPPLY
RETURN
