Table 12: Condenser marine water boxes, weights, 150# design, Victaulic
Shell
code
1 pass
(EA)
Kg 2 pass Kg Return Kg
3 pass
(EA)
Kg
Cover
plate
Kg
B 1222 2688.4 1271 2796.2 435 957 1255 2761 1798 3955.6
C 1391 3060.2 1491 3280.2 624 1373 1484 3264.8 2137 4701.4
D 1783 3922.6 2172 4778.4 1005 2211 2043 4494.6 2935 6457
E 1783 3922.6 2172 4778.4 1005 2211 2043 4494.6 2935 6457
F 2010 4422 2663 5858.6 1167 2567 2437 5361.4 3385 7447
K 2487 5471.4 3152 6934.4 154 339 2896 6371.2 4327 9519.4
L 875 1925 1024 2252.8 342 752 998 2195.6 1407 3095.4
M 875 1925 1024 2252.8 342 752 998 2195.6 1407 3095.4
Q 875 1925 1024 2252.8 276 607 993 2184.6 1183 2602.6
R 875 1925 1024 2252.8 451 992 998 2195.6 1406 3093.2
Table 13: Approximate unit motor weights, low voltage - English (metric)
60 Hz Hp Weight, lb Weight, kg 50 Hz Hp Weight, lbs. Weight, kgs
CT 503 2480 1,127 5C0 507 2635 1,198
CU 554 2480 1,127 5CP 546 2835 1,289
CV 608 2635 1,198 5CQ 575 2855 1,298
CW 655 2,835 1,289 5CR 617 3105 1,411
CX 690 2,835 1,289 5CS 658 3180 1,445
CY 740 3,105 1,411 5CT 704 5,750 2,614
CZ 790 3,180 1,445 5CU 750 5,750 2,614
CA 845 4,190 1,905 5CV 800 5,750 2,614
CB 900 5,750 2,614 5CW 850 6,800 3,091
DA 1000 6,800 3,091 5CX 900 6,800 3,091
DB 1100 6,800 3,091 5DA 1000 7,300 3,318
5DB 1100 7,300 3,318
29Centrifugal Liquid Chillers
