Figure 33: Compressor oil return piping
LD23316
K3, K4, and K7
Compressors
K3, K4, and K7
Compressors
K1 and K2
Compressors
Compressor #1
Compressor #2
Compressor #1 and 2
Condenser
H.P. Gas
Connection
From Compressor
Oil Return
Connection
To Oil Pump
Housing
From Evaporator
Oil Return
Connector
51Centrifugal Liquid Chillers
