Johnson Controls ZY Series User Manual

If components are to be added to a unit to meet
local codes, they are to be installed at the dealer’s
and/or customer’s expense.
The size of a unit for proposed installation should
be based on heat loss/heat gain calculation made
according to the methods of Air Conditioning
Contractors of America (ACCA).
This furnace is not to be used for temporary heating
of buildings or structures under construction.
Table 1: ZY04-12 Unit Limitations
Unit Limitations
Applied Voltage Outdoor DB Temp
Model
Size
(Tons)
Unit Voltage SCCR (kVA)
Min Max Max (°F)
208/230-1-60 5 187 252 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125
ZY
04
(3)
575-3-60 5 540 630 125
208/230-1-60 5 187 252 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125
ZY
05
(4)
575-3-60 5 540 630 125
208/230-1-60 5 187 252 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125
ZY
06
(5)
575-3-60 5 540 630 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125ZY
07
(6)
575-3-60 5 540 630 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125ZY
A7
(6)
575-3-60 5 540 630 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125ZY
08
(7.5)
575-3-60 5 540 630 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125ZY
09
(8.5)
575-3-60 5 540 630 125
208/230-3-60 5 187 252 125
460-3-60 5 432 504 125
ZY
12
(10)
575-3-60 5 540 630 125
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A12
