Johnson Controls ZY Series User Manual

ZY04 to 06 Bottom Duct Application (Direct Drive)
Table 50: ZY04 to 06 Bottom Duct (Cooling)
Available External Static
0.2 0.4 0.6 0.8 1.0
Unit (Ton) Motor Speed
CFM WATTS RPM CFM WATTS RPM CFM WATTS RPM CFM WATTS RPM CFM WATTS RPM
1 (LOW) 929 128 699 782 148 794 663 164 880 514 187 976 377 202 1053
2 (MED/LOW) 1036 157 732 870 177 827 803 198 905 649 217 996 508 236 1074
3 (MED) 1106 181 760 956 204 849 878 225 928 755 245 1010 616 266 1092
4 (MED/HI) 1147 197 776 1042 218 860 916 243 944 820 262 1017 671 286 1103
ZY04 (3)
5 (HI) 1272 252 830 1177 277 909 1037 304 986 975 323 1053 872 347 1125
1 (LOW) 1256 220 776 1170 242 851 1077 266 931 988 298 1025 872 321 1113
2 (MED/LOW) 1350 272 828 1279 292 893 1196 320 966 1105 347 1048 1003 372 1131
3 (MED) 1449 323 866 1380 350 937 1303 370 996 1223 402 1071 1133 428 1149
4 (MED/HI) 1488 345 882 1418 374 954 1357 394 1006 1264 424 1083 1160 442 1155
ZY05 (4)
5 (HI) 1677 471 966 1602 507 1034 1543 525 1083 1475 545 1131 1209 465 1162
1 (LOW) 1548 310 720 1441 336 792 1337 370 864 1213 397 928 1097 421 988
2 (MED/LOW) 1593 337 738 1488 363 805 1381 394 875 1271 425 937 1150 451 997
3 (MED) 1880 532 827 1792 563 890 1719 588 944 1632 629 1006 1527 652 1061
4 (MED/HI) 2066 689 895 1999 712 942 1907 761 999 1830 773 1048 1734 809 1100
ZY06 (5)
5 (HI) 2237 862 949 2163 882 996 2097 929 1036 1998 946 1085 1815 883 1115
Table 51: ZY04 to 06 Bottom Duct (Gas Heat)
Available External Static
0.2 0.4 0.6 0.8 1.0
Unit (Ton) Motor Speed
CFM WATTS RPM CFM WATTS RPM CFM WATTS RPM CFM WATTS RPM CFM WATTS RPM
1 (LOW) 969 130 703 839 151 810 717 174 916 569 191 1006 444 204 1069
2 (MED/LOW) 1063 158 741 955 180 834 828 204 938 709 227 1030 583 242 1100
3 (MED) 1135 182 769 1041 208 858 919 229 952 805 254 1045 681 275 1127
4 (MED/HI) 1310 256 842 1225 279 917 1123 307 1001 1029 334 1083 863 335 1155
ZY04 (3)
5 (HI) 1680 501 997 1622 526 1056 1538 546 1119 1296 485 1153 939 374 1176
1 (LOW) 1277 228 801 1196 251 878 1096 278 967 983 305 1062 873 329 1156
2 (MED/LOW) 1382 278 847 1307 302 916 1217 327 994 1108 355 1083 949 359 1164
3 (MED) 1486 331 888 1417 359 957 1331 385 1028 1237 410 1103 1023 385 1169
4 (MED/HI) 1717 473 991 1653 509 1052 1586 538 1107 1443 521 1150 1052 394 1175
ZY05 (4)
5 (HI) 2006 738 1132 1854 682 1147 1704 621 1154 1504 552 1168 1073 418 1177
1 (LOW) 1488 335 787 1400 363 851 1320 389 910 1242 416 969 1160 440 1027
2 (MED/LOW) 1536 364 803 1453 392 864 1363 419 924 1293 447 981 1212 471 1037
3 (MED) 1822 586 914 1752 602 966 1666 632 1017 1586 656 1066 1503 676 1113
4 (MED/HI) 1999 726 982 1932 761 1030 1860 809 1076 1753 799 1114 1598 749 1134
ZY06 (5)
5 (HI) 2170 932 1040 2091 930 1084 1965 910 1109 1798 843 1127 1618 763 1139
RPM Selection
Table 52: RPM Selection
Model
Size
(Tons)
Airflow
Option
Phase
MAX
BHP
Blower
Sheave
Motor
Sheave
6 Turns
Open
5 Turns
Open
4 Turns
Open
3 Turns
Open
2 Turns
Open
1 Turn
Open
Fully
Closed
Std. Direct Drive
Med. 1 1.5 AK46 1VL34 N/A 792 875 958 1042 1125 1208
Med. 3 2.4 AK46 1VL34 N/A 792 875 958 1042 1125 1208
ZY 04 (3)
H. Static 3 2.4 AK46 1VL44 N/A 1167 1250 1333 1417 1500 1593
Std. Direct Drive
Med. 1 1.5 AK46 1VL34 N/A 792 875 958 1042 1125 1208
Med. 3 2.4 AK46 1VL34 N/A 792 875 958 1042 1125 1208
ZY 05 (4)
H. Static 3 2.9 AK46 1VL44 N/A 1167 1250 1333 1417 1500 1593
Std. Direct Drive
Med. 1 1.5 AK46 1VL34 N/A 792 875 958 1042 1125 1208
Med. 3 2.4 AK46 1VL34 N/A 792 875 958 1042 1125 1208
ZY 06 (5)
H. Static 3 2.9 AK46 1VL44 N/A 1167 1250 1333 1417 1500 1593
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A 95
Johnson Controls Ducted Systems
