Johnson Controls ZY Series User Manual

Indoor Blower Specifications
Table 53: Indoor Blower Specifications
Motor Motor Sheave Blower Sheave
Model
Size
(Tons)
Airflow
Option
Phase
MAX
BHP
RPM Eff. SF Frame
Datum
Dia. (in.)
Bore
(in.)
Model
Datum
Dia. (in.)
Bore
(in.)
Model
Belt
Std. Direct Drive
Med. 1 1.5 1725 0.79 1.15 56HZ 1.9 - 2.9 5/8 1VL34 4.2 3/4 AK46 A39
Med. 3 2.4 1725 0.80 1.15 56Y 1.9 - 2.9 5/8 1VL34 4.2 3/4 AK46 A39
ZY 04 (3)
H. Static 3 2.4 1725 0.80 1.15 56Y 2.8 - 3.8 5/8 1VL44 4.2 3/4 AK46 A40
Std. Direct Drive
Med. 1 1.5 1725 0.79 1.15 56HZ 1.9 - 2.9 5/8 1VL34 4.2 3/4 AK46 A39
Med. 3 2.4 1725 0.80 1.15 56Y 1.9 - 2.9 5/8 1VL34 4.2 3/4 AK46 A39
ZY 05 (4)
H. Static 3 2.9 1725 0.81 1.15 56Y 2.8 - 3.8 7/8 1VL44 4.2 3/4 AK46 A40
Std. Direct Drive
Med. 1 1.5 1750 0.83 1.15 56H 1.9 - 2.9 5/8 1VL34 4.2 3/4 AK46 A37
Med. 3 2.4 1750 0.87 1.15 56HZ 1.9 - 2.9 5/8 1VL34 4.2 3/4 AK46 A37
ZY 06 (5)
H. Static 3 2.9 1750 0.87 1.15 56Z 2.8 - 3.8 7/8 1VL44 4.2 3/4 AK46 A39
Std. 3 2.4 1725 0.80 1.15 56Y 1.9 - 2.9 5/8 1VL34 7.0 1 AK74 A47
Med. 3 2.9 1725 0.81 1.15 56Y 2.8 - 3.8 7/8 1VL44 7.0 1 AK74 A48ZY 07 (6)
H. Static 3 3.7 1725 0.84 1.15 56HZ 3.4 - 4.4 7/8 1VP50 7.0 1 AK74 A48
Std. 3 2.4 1725 0.80 1.15 56Y 1.9 - 2.9 5/8 1VL34 7.0 1 AK74 A47
Med. 3 2.9 1725 0.81 1.15 56Y 2.8 - 3.8 7/8 1VL44 7.0 1 AK74 A48ZY A7 (6)
H. Static 3 3.7 1725 0.84 1.15 56HZ 3.4 - 4.4 7/8 1VP50 7.0 1 AK74 A48
Std. 3 2.4 1725 0.80 1.15 56Y 1.9 - 2.9 5/8 1VL34 7.0 1 AK74 A47
Med. 3 2.4 1725 0.80 1.15 56Y 2.8 - 3.8 5/8 1VL44 7.0 1 AK74 A48ZY 08 (7.5)
H. Static 3 3.7 1725 0.84 1.15 56HZ 3.4 - 4.4 7/8 1VP50 7.0 1 AK74 A50
Std. 3 2.4 1725 0.80 1.15 56Y 1.9 - 2.9 5/8 1VL34 7.0 1 AK74 A47
Med. 3 2.4 1725 0.80 1.15 56Y 2.8 - 3.8 5/8 1VL44 7.0 1 AK74 A48ZY 09 (8.5)
H. Static 3 3.7 1725 0.84 1.15 56HZ 3.4 - 4.4 7/8 1VP50 7.0 1 AK74 A50
Std. 3 2.4 1725 0.80 1.15 56Y 2.8 - 3.8 5/8 1VL44 7.5 1 AK79 A50
Med. 3 3.7 1725 0.84 1.15 56HZ 3.4 - 4.4 7/8 1VP50 7.5 1 AK79 A50
ZY 12 (10)
H. Static 3 5.25 1725 0.84 1.15 145TY 4.3 - 5.3 7/8 1VP56 7.9 1 BK85 BX52
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A 97
