Johnson Controls ZY Series User Manual

Smart Equipment
™
Control Board Navigation
Components
The following components are needed to access
the control points in the Smart Equipment
™
control.
Installation and operation guides are available from
your equipment dealer or distributor.
1. Local LCD on Unit Control Board.
2. Mobile Access Portal (MAP) Gateway
(Portable).
- Source 1 P/N S1-JC-MAP1810-OP
3. MAP Gateway Quick Start Guide P/N
24-10737-16
4. MAP Gateway Instruction P/N 24-10737-8
For more information on the Smart Equipment
™
unit control board navigation, refer to the Smart
Equipment
™
Quick Start Guide.
Note: For more in-depth sequence of operation
of the Smart Equipment
™
control, refer to
the Smart Equipment
™
Controls Sequence of
Operation Overview LIT-12011950.
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A138
Johnson Controls Ducted Systems
