Johnson Controls ZY Series - Physical Data; ZY04 to ZY12 Physical Data

Physical Data
ZY04 to ZY12 Physical Data
Table 17: ZY04 Physical Data
Models
Component
ZYG04 ZYE04
Nominal Tonnage 3 3
Gross Capacity @ AHRI A point (Btu) 40700 40700
AHRI net capacity (Btu) 36000 36000
EER 12 12
SEER 15 15
IEER - -
IEER IntelliSpeed - -
Nominal CFM 1200 1200
System power (KW) 2.60 2.60
Refrigerant type R-410A R-410A
Refrigerant charge (lb-oz)
System 1 4-10 4-10
AHRI COOLING PERFORMANCE
System 2 - -
Heating Option L D M E -
Heating model Low (Low-NOx) Low Med (Low-NOx) Med -
1st. Stage Heat input (K Btu) - - - - -
2nd. Stage Heat input (K Btu) 56 70 90 112 -
1st. Stage Heat output (K Btu) - - - - -
2nd. Stage Heat output (K Btu) 45 56 72 90 -
AFUE % - - - 81 -
FER Compliant - - - Yes -
No. burners 2 2 3 3 -
No. stages 1 1 1 1 -
Temperature Rise Range (ºF) 10-40 20-50 35-65 50-80 -
Gas Limit Setting (ºF) 150 150 140 140 -
AHRI HEATING
PERFORMANCE SINGLE PHASE
Gas piping connection (in.) 1/2 1/2 1/2 1/2 -
Heating Option L D M E -
Heating model Low (Low-NOx) Low Med (Low-NOx) Med -
1st. Stage Heat input (K Btu) - 49 - 82 -
2nd. Stage Heat input (K Btu) 56 70 90 112 -
1st. Stage Heat output (K Btu) - 39 - 66 -
2nd. Stage Heat output (K Btu) 45 56 72 90 -
Steady state efficiency (%) 80 80 80 80 -
No. burners 2 2 3 3 -
No. stages 1 2 1 2 -
Temperature Rise Range (ºF) 28-46 35-58 44-74 55-78 -
Gas Limit Setting (ºF) 150 150 140 140 -
AHRI HEATING
PERFORMANCE THREE PHASE
Gas piping connection (in.) 1/2 1/2 1/2 1/2 -
Length 74.1 74.1
Width 48.9 48.9DIMENSIONS (in.)
Height 32.5 32.5
OPERATING WT. (lb) 527 481
Type Scroll Scroll
Quantity 1 1COMPRESSORS
Unit Capacity Steps (%) 100 100
Face area (Sq. Ft.) 16.3 16.3
Rows 1 1
Fins per inch 23 23
Tube diameter (in./MM) .63/16 .63/16
CONDENSER COIL DATA
Circuitry Type 2-pass Microchannel 2-pass Microchannel
Face area (Sq. Ft.) 5.5 5.5
Rows 3 3
Fins per inch 15 15
Tube diameter 0.375 0.375
Circuitry Type Intertwined Intertwined
EVAPORATOR COIL DATA
Refrigerant control TXV TXV
