CHAPTER 6: Part Replacement Guide
27
6.3 SIDE RAIL REPLACEMENT
1) Remove the rear end cap (Fig-1 & Fig-2)
Fig-1 Fig-2
2) Slide the rail off the back of the treadmill
3) Reverse Steps 1-2 to install a new side rail.
NOTE: After reinstalling the side rail, make sure the rear end cap is on first before tightening the screws for proper
gap spacing. Be careful not to over tighten the screws, or they will poke through the top of the side rail.
