Johnson AFG Series - Front Roller Replacement

CHAPTER 6: Part Replacement Guide
29
6.5 FRONT ROLLER REPLACEMENT
1) Remove the motor cover as outlined in Section 4.1.
2) Loosen both of the rear roller screws to remove tension from the running belt (Figure1).
Fig-1
5) Remove the drive belt from the front roller and remove the roller from the running belt.
