CHAPTER 3: Electrical Connection System
15
3.3 MCB CIRCUIT BOARD INSTRUCTIONS
5.5AT MCB
CN1
Power line
CN2
Incline motor power connector
CN3
Console cable connector
CN4
Speed sensor connector
CN5
Drive motor connector
