PEDAL AXLE-PULLEY ASSEMBLY REPLACEMENT

PROCEDURE (JPC/B)

Tools required:

u Philips

screwdriver

u C-clip pliers

u Crank extractor

u Coin

u Hex key (4mm)

u Open-end

wrench

(14&17 mm)

Procedure:

5. Remove the c-clip (C) by using the c-clip pliers and

remove the metal pulley from the generator using the

Bearing Puller.

6. Remove the c-clip (D) by using the c-clip pliers and

remove the idler using the Bearing Puller.

7. Remove the c-clip (B) by using the c-clip pliers and

remove the Bearing Housing using the Bearing Puller.

8. Replace the axle-pulley assembly with a new one.

9. Reverse step 1-9 to install the parts.

3-10 Revision: 1.0 Date: 2001/06/01
