Johnston VT502 - Page 10

V Range 502 l 652 l 802 Maintenance Manual
MA1:8
Chapter - Scheduled Maintenance
Area Remove / Ret Time Taken
(Mins)
Special Tools
Required
1 or 2
Persons
Water System Hose reel 60 None
1
Water System Low pressure spray bar (Located under
front spray bar)
30 None
1
Water System Low pressure nozzle (Includes cleaning
nozzle (All nozzles)
10 None
1
Water System Low pressure gutter spray (Includes
cleaning nozzles)
20 None
1
Water System High pressure spray bar (Located
under front bumper)
30 None
1
Water System High pressure spray bar mounting
(Spray bar removed)
15 None
1
Water System Suction box low pressure nozzles 15 None
1
Water System Suction box high pressure spray bar 10 None
1
Water System Nozzles (Includes cleaning) 15 None
1
Water System Wander hose low pressure nozzle
(Includes cleaning)
10 None
1
Water System Wander hose low pressure water tap 15 None
1
Water System Supa-wash pump (Includes check and
top up hydraulic oil level)
60 None
1
Water System Water solenoids (Includes cleaning seal
and valve - each)
15 None
1
Water System High pressure water tap (Front high
pressure spray bar and suction box
high pressure spray bar - each)
20 None
1
Water System Water ller neck lter (hydrant ller) 10 None
1
Water System Water tank suction lter 15 None
1
Water System Water tank breather 25 None
1
Water System Water lter assembly (R/H rear) 30 None
1
Electrical
System
Centre Console (Including software
update and test)
20 TB1570
1
Electrical
System
JVM Screen (Including software update
and test)
30 TB1555 & TB1570
1
Electrical
System
Keypad Node (Including software
update and test)
20 None
1
Electrical
System
Pendant (Including software update
and test)
15 None
1
This Guide Detail the time taken to remove, ret and validate the item listed. Where the task is listed as 2
person the total time taken is shown in the table however certain aspects of the tasks may require 2 persons
for the safe completion of the task.
NOTICE:
Used oils and filters should be disposed of in accordance with local waste disposal
regulations.
These procedures should be carried out by qualified service personnel.
