Johnston VT502 - Page 11

MA1:9
V Range 502 l 652 l 802 Maintenance Manual
Johnston Sweepers Limited
Chapter - Scheduled Maintenance
Area Remove / Ret Time Taken
(Mins)
Special Tools
Required
1 or 2
Persons
Electrical
System
Multi-camera Module (Including
software update and test)
20 None 1
Electrical
System
Systems Locker Node (Including
software update and test)
15 None
1
Electrical
System
Powapack Node (Including software
update and test)
15 None
1
Electrical
System
Subframe Node (Including software
update and test)
25 None
1
Electrical
System
High Current Node (Including software
update and test - each)
25 None
1
Electrical
System
Pneumatic Valve Island (Including
software update and test - each)
30 None
1
Electrical
System
Emergency hydraulic pump (Including
test)
45 None
1
Electrical
System
Rear beacon (each) 15 None
1
Engine Skid
Unit
Engine tub assembly 480 None
1
Maintenance 50 Hour Service 90 None
1
Maintenance ‘A’ Service 180 None
1
Maintenance ‘B’ Service 300 None
1
Maintenance ‘C’ Service 420 None
1
Maintenance ‘D’ Service 500 None
1
This Guide Detail the time taken to remove, ret and validate the item listed. Where the task is listed as 2
person the total time taken is shown in the table however certain aspects of the tasks may require 2 persons
for the safe completion of the task.
NOTICE:
Used oils and filters should be disposed of in accordance with local waste disposal
regulations.
These procedures should be carried out by qualified service personnel.
