Johnston VT502 - Page 7

MA1:5
V Range 502 l 652 l 802 Maintenance Manual
Johnston Sweepers Limited
Chapter - Scheduled Maintenance
Area Remove / Ret Time Taken
(Mins)
Special Tools
Required
1 or 2
Persons
Hopper Side Locker Door 10 none
1
Hopper Side Locker Gas strut 10 none
1
Hopper Side Locker door catch mechanism 10 none
1
Hopper Side Door (each) 10 none
1
Hopper Side Door Seal (each) 25 none
1
Hopper Side Door lock and catch (each) 15 none
1
Hopper Mesh Screen (each) 10 none
1
Hopper Body Tip Cylinder 60 none
1
Hopper Body tip Hinges 120 none
1
Hopper Door Lock Hydraulic cylinder 25 none
1
Hopper Door Lock Proximity switch (each) 10 none
1
Hopper Rear Door Chute plate 30 none
1
Hopper Wear Plate (each) 30 none
1
Hopper Intake Duct 45 none
1
Hopper Centre Bafe (Dual machines only) 15 none
1
Hopper Rear Door 70 none
1
Hopper Rear Door Cylinder 35 none
1
Hopper Rear Door Seal 30 none
1
Hopper Fan Case Seal 20 none
1
Hopper Cowl Seal 45 none
1
Hopper Cowl NAF 90 none
1
Hopper Intake duct ap air cylinder 15 80 bar Pressure
1
Hopper Intake duct ap Actuator 10 none
1
Hopper Intake duct ap 10 TB1556 1
Hopper Intake duct ap Shaft 60 none 1
Hopper
Flap shaft bush (inside body) 30 none
1
Hopper Flap shaft bearing (outside body) 15 none
1
Subframe Body tip mount. 40 none
1
Subframe Water lter assembly 30 none
1
Subframe Body prop 15 Workshop body prop
PN:7030765
1
Subframe Body prop release assembly 25 none
1
This Guide Detail the time taken to remove, ret and validate the item listed. Where the task is listed as 2
person the total time taken is shown in the table however certain aspects of the tasks may require 2 persons
for the safe completion of the task.
STANDARD REPAIR TIMES (SRT)
NOTICE:
Used oils and filters should be disposed of in accordance with local waste disposal
regulations.
These procedures should be carried out by qualified service personnel.
