V Range 502 l 652 l 802 Maintenance Manual
MA1:6
Chapter - Scheduled Maintenance
Area Remove / Ret Time Taken
(Mins)
Special Tools
Required
1 or 2
Persons
Sweepgear Channel Brush position ram (Includes
check and top up hydraulic oil)
30 None
1
Sweepgear Channel brush curtain (each) 10 None
1
Sweepgear Channel brush kick back fork (Includes
replacement of spring)
20 None
1
Sweepgear Channel brush lift ram 15 None
1
Sweepgear Channel brush motor (with brush and
brush plate removed). Includes check
and top up of hydraulic oil
25 None
1
Sweepgear Channel brush motor mounting (with
motor, brush and brush plate removed)
10 None
1
Sweepgear Brush plate (with brush removed) 10 None
1
Sweepgear Brush head 10 None
1
Sweepgear Nozzle assembly 30 None
1
Sweepgear Nozzle carriage (Nozzle assembly
removed)
15 None
1
Sweepgear Nozzle rubbers 30 None
1
Sweepgear Nozzle water jets (low pressure) 15 None
1
Sweepgear Nozzle tow bar (With tow eye removed) 25 None
1
Sweepgear Nozzle tow eye 10 None
1
Sweepgear Nozzle box lift cylinder (each) 15 None
1
Sweepgear Maxi gap cylinder 15 None
1
Sweepgear Carriage wheel (Includes remove and
ret auto lube pipe)
10 None
1
Sweepgear Nozzle box bumper 10 None
1
Sweepgear Trunking 10 None
1
Wide Sweep
Brush
WSB Assembly (Dual and single
machines )
90 None
1
Wide Sweep
Brush
Brushes (Replace) 30 None
1
Wide Sweep
Brush
Tow bar (Includes removal and retting
of WSB and brushes)
40 None
1
Wide Sweep
Brush
Tow bar compensator (Includes
removal and retting of WSB, brushes
and tow bar)
45 None
1
Wide Sweep
Brush
Brush motor (Includes removal and
retting of brushes)
75 None 1
This Guide Detail the time taken to remove, ret and validate the item listed. Where the task is listed as 2
person the total time taken is shown in the table however certain aspects of the tasks may require 2 persons
for the safe completion of the task.
NOTICE:
Used oils and filters should be disposed of in accordance with local waste disposal
regulations.
These procedures should be carried out by qualified service personnel.
