13 - 40
cube
Model
Dimensions
(W x D x H)
[mm]
Power supply
Consumption
[W]
Electrical
absorption
[mA]
(*) Lp eq according
to UNI-EN 3746
[dB(A)]
Weight
[kg]
JONIX cube
238 x 238 x 260 230 V / ~1 / 50Hz 10 51 33 4
(*): Equivalent sound pressure values (Lp eq) at a distance of 1m according to UNI-EN 3746 (Determination of sound
power levels and sound energy levels of noise sources by measuring sound pressure - Control method using an enveloping
surface over a reflecting plane), obtained starting from the values of sound power (Lw) determined with the tests in a
reverberation room.
4.1.1 Technical features JONIX cube
4.1.2 Spare parts available on order
Code Description Notes
71KT000001 CUBE GENERATORS SPARE PART KIT 2 Ionising generators
JX40000001 CUBE POWER CABLE
3x0.75 cable, SP8848 schuko plug
and 90° IEC60320 C13 connector
JX40000002 PROTECTION FUSE 1 quick blow glass fuse 5x20 1A ‘F’
