20
2
Starter unit
!
!
B. Press down a new spring in the starter
housing.
B. Return spring without cassette.
Leave the lock shackle round the
spring in position.
1. Place the spring over its seat in the
starter housing.
2. Press down the spring in the correct
position by means of the thumbs and
let the lock shackle slide over the
spring.
3. Fit the cover plate off the spring.
Replacing starter cord
1. Fit and lock the cord at the pulley as
per one of the methods shown in the
diagrams.
Tips!
The knot on the starter cord in the starter
handle may be difficult to untie. It is easier
if the knot is first knocked with a hammer
against a hard surface.
2. Anchor the cord in the starter handle. 2. Enter the cord through the socket in
the starter housing and anchor it in
the starter handle by means of a knot.
Fold down the free end and pull the
knot securely into the handle.
WARNING!
Wear protective glas-
ses.
WARNING!
Wear protective glas-
ses.
