How To Assemble This Tricycle
Assembly Instrucons
Your trike has been pre-assembled. It requires only a few simple steps to get it ready for your rst ride.
1. Remove the outside carton aer cung the nylon bands and taking o the lid. Carefully remove your trike from the
box and gently rest it in place.
2. Remove all the inside cardboard protecon and bubble wrap.
3. Locate and set aside the kit box containing the pedals, this user’s manual, and tool kit.
4. Install the front wheel by lining up the disc brake and place the fork of the trike onto the front wheel. (You may need
to remove the spacer between the disc brake pads)
5. Insert the quick release skewer & turn the skewer adjusng nut clockwise to ghten it. Keep turning the adjusng
nut unl you see or feel the nut contact the face of the dropout.
6. Next, try closing the lever. Your goal is to ghten the adjusng nut enough so that the lever can be fully closed and
closing it requires signicant force. You want it to be hard to close, you want to see a lever mark on your hand. If the
lever is not hard to close, hold the lever and further ghten the adjusng nut, try again. If not possible to close or its
very, very hard to close, hold the lever and slightly loosen the adjusng nut, try again. Towards the end of the
adjustment process, quite small changes, like ½ turn, of the adjusng nut are necessary. Your goal is to ghten the
