Jorvik JMT Mid Drive Electric Mountain Trike
Page | 9
Fing the Stem JMT 7 13
1. Remove the white safety
cover/spacer.
2. Make sure the front fork is aligned to
the wheel.
3. Mount the handlebar onto the top of
the front fork stem.
4. Tighten the stem down with a 5mm
hex key.
5. Tighten the 2 pinch bolts on the stem
with a 5mm hex key.
6. Adjust the height by slacking the
single 5mm bolt on the right side of
the stem and adjusng the angle as
required. Then ghten.
7. Adjust the bar rotaon undoing the 4
x 4mm bolts on the face plate then
ghten evenly checking that the bars
do not move under pressure.
1.
2.
