Jøtul C 450 Parts List
No. Description Part Number
1. Control Door, Crosshatch Grille - Matte Black 10398092
Control Door, Crosshatch Grille - Blue Black 10398027
Control Door, Crosshatch Grille - Jøtul Iron Gray 10398085
2. Ashlip - Matte Black 10397992
Ashlip - Blue Black 10397927
Ashlip - Jøtul Iron Gray 10397985
3. Kenn. Surround Leg, Left - Matte Black 10425992
Kenn. Surround Leg , Left - Blue Black 10425927
Kenn. Surround Leg, Left - Jøtul Iron Gray 10425985
4. Kenn. Surround Leg, Right - Matte Black 10426092
Kenn. Surround Leg, Right - Blue Black 10426027
Kenn. Surround Leg, Right - Jøtul Iron Gray 10426085
5. Kenn. Breastplate, Left - Matte Black 10425792
Kenn. Breastplate, Left - Blue Black 10425727
Kenn. Breastplate, Left - Jøtul Iron Gray 10425785
6. Kenn. Breastplate, Right - Matte Black 10425892
Kenn. Breastplate, Right - Blue Black 10425827
Kenn. Breastplate, Right - Jøtul Iron Gray 10425885
7. Door, Left - Matte Black 10397492
Door, Left - Blue Black 10397427
Door, Left - Jøtul Iron Gray 10397485
8. Door, Right - Matte Black 10397592
Door, Right - Blue Black 10397527
Door, Right - Jøtul Iron Gray 10397585
9. Firebox 220317
10. Shroud Front, Adjustable - Matte Black 22033892
Shroud Front, Adjustable - Jøtul Iron Gray 22033885
11. Shroud, Cabinet Sleeve 220315
12. Shroud, Back Panel 220312
13. Air Inlet Collar, 3” dia. 220502
14. Air Channel, Back / Bottom 220308
15. Shroud, Bottom 220309
16. Air Channel, Front 220307
17. Air Valve Handle 220318
18. Front Plate 103973
19. Blower Shroud (Heat Shield) 220501
20. Extension Shroud Retainer Clip, (3) 222096
21. Ashlip Support - Right 220385
22. Ashlip Support - Left 220386
23. Shroud Extension, Bottom 220310
24. Joint Hinge, Loose Leaf (2) 220335
25. Pin Leaf, left 220334
26. Pin Leaf Right 220333
27. Hang Tab 129680
28. Door Latch 220340
29. Roll Pin, 5 x 35 127064
30. Door Handle (Stove Tool) 154310
31. Air Manifold, Secondary 220305
32. Baffle Plate 103983
33. Latch, Receiver - Double Door 220349
34. Air Slider 104082
35. Inspection Cover 103985
36. Brick Retainer 103984
37. Hang Tab, Surround Panels, (4) not shown 129680
38. Glass Panel, (2) - Double Door 220356
39. Glass Retainer, (4) 125942
40. Refractory Brick, (13) 129082
41. Refractory Brick, 9” x 2” (2) 220390
42. Refractory Brick, 1 5/8” x 4 1/2” (1) 220391
43. Refractory Brick, 9” x 3” (2) 220518
44. Gasket, 3/8” LD Rope ( Baffle) 100038
45. Gasket, 1/4” LD Rope / Self-adhesive (Glass) 200024
46. Gasket, 3/8” LD Rope (Front Plate, Doors) 100038
47. Gasket, Inspection Cover 220513
48. Baffle Support, (2) 220306
49. Blower 220522
50. Convection Air Rod (Trim Rod) Matte Black 22053192
Convection Air Rod (Trim Rod) Jøtul Iron Gray 22053185
51. Miscellaneous Hardware Bag* 155613
52. Baffle Assembly, Complete 153309
53. Tam. Grille Shade - Matte Black 22050492
Tam. Grille Shade - Jøtul Iron Gray 22050485
54. Tam Keystone - Matte Black 10398192
Tam Keystone - Blue Black 10398127
Tam Keystone - Jøtul Iron Gray 10398185
55. Tam. Surround Leg - Matte Black 10397692
Tam. Surround Leg - Blue Black 10397627
Tam. Surround Leg - Jøtul Iron Gray 10397685
56. Tam. Breastplate, Left - Matte Black 10397792
Tam. Breastplate, Left - Blue Black 10397727
Tam. Breastplate, Left - Jøtul Iron Gray 10397785
57. Tam. Breastplate, Right - Matte Black 10397892
Tam. Breastplate, Right - Blue Black 10397827
Tam. Breastplate, Right - Jøtul Iron Gray 10397885
58. Front Assembly, Single Door - Matte Black 157039
Front Assembly, Single Door - Blue Black 157038
Front Assembly, Single Door - Jøtul Iron Gray 157040
59. Replacement Single Door - Matte Black 157036
Replacement Single Door - Blue Black 157035
Replacement Single Door - Jøtul Iron Gray 157037
60. Control Door, Vertical Grille - Matte Black 157042
Control Door, Vertical Grille - Blue Black 157041
Control Door, Vertical Grille - Jøtul Iron Gray 157043
61. Glass Panel, Single Door 222991
62. Latch Receiver, Single Door 225398
63. Hinge Pin, Black (2) 127075
Hinge Pin, Nickel (2) 125960
64. M6 x 14 Button Head Cap Screw, (2) 118215
65. Washers, .062 (6) 117947
Jøtul C 450 Options
Mantel Heat Shield ..............................................................................155833
Kennebec Classic Surround Panel Kit, 40” x 30 1/4”
Matte Black ...................................................................................350577
Blue Black .....................................................................................350578
Jøtul Iron ..................................................................................... 350579
Tamarack Lattice Surround Panel Kit, 40” x 30 1/4”
Matte Black ...................................................................................350557
Blue Black .....................................................................................350558
Jøtul Iron ..................................................................................... 350559
Wide Surround Panel Kits, 47 5/8” x 34”
Matte Black ...................................................................................155323
Blue Black ...................................................................................155324
Jøtul Iron ....................................................................................155354
