6
138344_Rev_D - C450 Kennebec 8.2.10
Jøtul C 450 Specifications
Performance
Fuel: 20” Logs
Heat Output
1
: 50,000 BTU/hr. (4.1 kg/hr.)
Heating Capacity
2
: 1,100 - 1,600 sq. ft.
Overall Efficiency
3
: 71%
Emissions: 4.4 grams/hr.
Burn Time: 4-9 hours
Optional Blower: 125 cfm.
Shipping Weight: 445 lbs. (202 kg.)
1
Maximum Heat Output based on total
kilograms of dry wood burned in a one
hour period.
2
Heating Capacity and Maximum Burn
Time will vary depending on design of
home, climate, wood type and
operation.
3
Overall Efficiency is based on a burn rate
of .99 kg wood per hour.
The Jøtul C450 Fireplace Insert meets U.S.
EPA emission limits for wood heaters sold
after July 1990, and are tested and listed to
ANSI/UL 1482, and CAN/ULC S628.93. It is
intended for installation in accordance with
NFPA 211 or CAN/CSA B365.
to Door Opening
Surround
Panel
Figure 4. Flue Collar Centerline from Front Face
Figure 3. Overall Surround Dimensions are the same for both
Kennebec and Tamarack styles. (Kenebec with double-doors
shown here).
Figure 2. Minimum Sleeve Adjustment
Figure 1. Maximum Sleeve Adjustment
Firebox
Sleeve
Firebox
Sleeve
Firebox
Firebox
to Door
Opening
2 7
Surround Panel
