Jøtul F 520 User Manual

10
ENGLISH
Fresh air supply
Theairusedforcombustioninanywell-insulatedhouseneeds
to be replaced. This is particularly important in houses with
mechanicalventilation.Suchreplacementaircanbeprocured
inseveralways.Themostimportantthingistosupplytheair
totheroomwherethestoveisplaced.Placetheoutsidewall
valveasclosetothestoveaspossibleandmakesurethatit
can be closed when the stove is not in use.
For the fresh air supply connection, follow the national and
local building regulations.
Closed combustion system
Usethestove’sclosedcombustionsystemifyouliveinrecently
built,airtightdwellings.Connecttheexternal combustion air
throughaventilationpipethroughthewallortheoor.
Air supply
TheamountofcombustionairforJøtul’sproductsisapproximately
20-40m
3
/h.Theoutsideairconnectionmaybetteddirectlyto
the Jøtul F 520 through:
• thebottom/rear
• through a exible supply hose from the outside/chimney
(onlyifthechimneyhasitsownductforexternalair)andto
theproduct’soutsideairconnector.
•
Fig. 2A, through an outside wall
Fig. 2B,throughtheoorandgroundplate
Fig. 2C,throughtheoorandbasement
Fig. 2D, indirectly through an outside wall

Jøtul F 520 Specifications

General

Fuel Type	Wood
Max Log Length	20 inches
Flue Outlet	Top or Rear
Flue Size	6 inches
Model	F 520
Category	Indoor Fireplace
Type	Freestanding
Firebox Material	Cast Iron
EPA Certified	Yes
Efficiency	75%
Emissions	2.5 g/hr
