Jøtul F 520 User Manual

7
ENGLISH
3.0 Safety
NB! To guarantee optimal performance and safety, Jøtul
recommends that its stoves are tted by a qualied
installer (see www.jotul.com for a complete list of dealers).
Anymodicationstotheproductbythedistributor,installeror
consumermayresultintheproductandsafetyfeaturesnot
functioningasintended.Thesameappliestotheinstallationof
accessoriesoroptionalextrasnotsuppliedbyJøtul.Thismay
also be the case if parts that are essential to the functioning and
safetyofthereplacehavebeendisassembledorremoved.
Inallthesecases,themanufacturerisnotresponsibleorliable
fortheproductandtherighttomakeacomplaintbecomesnull
and void.
NB: Parts of the stove, in particular, the external surfaces, get
hotduringcombustion!Exercisecaution!
3.1 Fire Prevention Measures
There is a certain element of danger every time you use
your replace. The following instructions must therefore be
followed:
• Theminimumsafetydistanceswheninstallingandusing
thereplacearegivening. 1.
• Ensure that furniture and other ammable materials are
nottooclosetothereplace.Flammablematerialsshould
notbeplacedwithin900mmofthereplace.
• Allowtheretoburnout.Neverextinguishtheameswith
water.
• Thereplacebecomeshotwhenlitandmaycauseburns
if touched.
• Only remove ash when the replace is cold. Ash can
contain hot embers and should therefore be placed in a
non-ammablecontainer.
• Ashshouldbeplacedoutdoorsorbeemptiedinaplace
whereitwillnotpresentapotentialrehazard.
In case of chimney re:
• Close all hatches and vents.
• Keepthereboxdoorclosed.
• Checktheloftandcellarforsmoke.
• Callthereservice.
• Beforeuseafterareanexpertmustcheckthereplace
andthechimneyinordertoensurethatitisfullyfunctional.
Steel chimney
If a top-mounted steel chimney is used, t an uninsulated
pipefromthe burn chambertoapprox. 10 mmoverthe top
grate. Make sure that the gasket is properly seated between
theuepipeandthesmokeoutlet.Thentthesteelchimney
in accordance with the chimney supplier’s installation
instructions.
3.2 Floor
Foundation
Youneedtomakesurethefoundationissuitableforareplace.
See “2.0 Technical Data”forspeciedweight.
Werecommendtheremovalofanyooringthatisnotattached
tothefoundation(“oatingoors”)beneaththeinstallation.
Requirements for protection of
inammable oors in front of the
replace
Thefrontplatemustcomplywithnationallawsandregulations.
Contact your local building authorities regarding restrictions
andinstallationrequirements.
3.3 Walls
Distance to walls made of combustible material - see g. b
Distance to combustible wall protected by rewall: See
g. 1c.
The replace may be used with an uninsulated ue pipe
providedthedistancesbetweenthereplaceandwallsmade
ofcombustiblematerialsareasshowning. 1b. Alternative
distances with shielded or insulated ue pipe are also
displayeding.1b.
NB: Place the product in such a way that it is possible to clean
thestove,theuepipeandthechimneypassage.
Note! Ensure that furniture and other ammable materials
are not too close to the replace. Flammable materials
should not be placed within 900 mm of the replace.
NB: Makesurethatfurnitureandotherhouseholditemsare
not so close as to get dried up by the stove.
3.4 Ceiling
The fireplace can be fitted with the top edge of the hot air
opening of the surround at least 750 mm below a ceiling
of inflammable material.

Jøtul F 520 Specifications

General

Fuel Type	Wood
Max Log Length	20 inches
Flue Outlet	Top or Rear
Flue Size	6 inches
Model	F 520
Category	Indoor Fireplace
Type	Freestanding
Firebox Material	Cast Iron
EPA Certified	Yes
Efficiency	75%
Emissions	2.5 g/hr
