36
NEDERLANDS
Jøtul F 520
Minimale afstand tot brandbare muur
Brandbare muur
Fig. 1 a
Gaten in de muur ten behoeve van externe lucht
Ø80 / Ø100 mm verbinding
Gaten in de vloer ten behoeve van externe lucht.
Ø 100 mm verbinding
Minimale hoogte vanaf meubels/
brandbare materialen:
Minimale afmetingen voor de vloerplaat.
X,Y = In overeenstemming met nationale wet- en regelgeving.
900187-P00
594
1000
532
269
442
354
584
130 - 150
848
562
1199
1027
848
600
562
700
997
742
473
300
900
Y
X
