Joyner JNSZ650DLB - Page 55

Figure 68 Figure 69
Figure 70 Figure 71
2) Install thin pivot plate and long crank. (see Figure 72
Figure 73
Figure 72 Figure 73
Thick pivot plate
Shifter shaft
Shifter shaft
Short crank
Shifter shaft
Short crank
Nut
Washer
Spring washer
Step 1 finished
Thin pivot plate
Thin pivot plate
