File Number: JG-MCYF-SM-0039
3.1 GUI Operation
Software Installation
Figure 12 Installation Package and Driver
Installation steps: decompress installation package → install driver → install software library
→ open TypeE-GUI software
3.1.1 Serial COM Port
1) Connecting method
Using USB TO RS232 cable to connect PC’s USB and the Laser’s RS-232 connector.
Click and open the Serial COM Number as follow:
After connecting the data line, check the serial port number: my computer → properties
→ hardware → device manager →
If the Serial Port Number is bigger than 4, revise the COM number to ≤4
Figure 13 The Selection of GUI Serial Port Connection
