YDFLP-E-80&100-M7-M-R User Manual
1
File Number: JG-MCYF-SM-0039
1. Product Introduction
1.1 Product Description
JPT E-M7 Series fiber laser control with standard DB25 interface and powered with 48V DC.
It is designed for high-speed and precise marking application. The pulse response and
performance are much better comparing to similar products. Significantly compact size is ideal
for small marking system.
Photographs of typical E-M7 type fiber lasers are shown in Fig.2 and Fig.3 ( For the specific
appearance, please refer to the appearance of the product shipped):
Figure 2 YDFLP-E-80&100-M7-M-R
1.2 Packing List
Please refer to the packing list according to table 2.
Table 2 Packing List of YDFLP
Item
Quantity
Fiber Laser
1
Testing Report
1
Power Cable
1
Dust Cap for Laser Isolator
1
Laser Usage Notes
1
Product List
1
