YDFLP-E-80&100-M7-M-R User Manual
3
File Number: JG-MCYF-SM-0039
window will cause heat and damage the lens, which results in output power decrease even
laser damage.
7. Please make sure that the power is off before installing and uninstalling.
8. Please do not look at the output window anytime when power on, and wear laser safety
goggle when operating the fiber laser.
9. YDFLP-E-80&100-M7-M-R contains 17 wave-forms: CW, 2ns, 4ns, 6ns, 9ns, 13ns, 20ns,
30ns, 45ns, 60ns, 80ns, 100ns, 150ns, 200ns, 250ns, 350ns, 500ns.
Other pulse width is available for customization request.
1.4 YDFLP Product Naming Convention
Table 3 Naming Convention for Pulsed Fiber Laser
YDFLP – X – XX – XX – X – X
1 2 3 4 5 6
1. Product Name：Ytterbium Doped Fiber Laser Pulse (YDFLP)
2. Product type
3. Average Output power
4. Pulse Characteristics:
M7 series - adjustable pulse width
LP series - fixed pulse width
5. Optical Fiber attributes：
M: Near single mode, M²＜1.4
L: Low mode, M²＜1.8
H: High mode, M²＞2.5
6. Additional function
：
R: Built-in red pilot laser
Examples：
YDFLP-E-50-LP-L: Type E LP, using low mode type of optical fiber with nominal output power
50W.
YDFLP-80-M7-M-R: M7, using near single mode type of optical fiber with the nominal output
power 80W, built-in red pilot laser.
